Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200CX
Edition
Network Advantage
Manufacturer
Cisco Systems
Flash Memory Installed
8 GB
RAM Installed
4 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ae, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
802.1x authentication, Access Control List (ACL) support, Class of Service (CoS), Committed Information Rate (CIR), Control plane protection (CoPP), DiffServ Code Point (DSCP) support, Embedded Event Manager (EEM), Energy Efficient Ethernet, Fanless, First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Management Information Base (MIB), NetFlow, Protocol Independent Multicast (PIM), PVLAN support, PXE support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Switched Port Analyzer (SPAN)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
PoE Budget
240 watt
Ports
12
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, YANG
Routing Protocol
EIGRP, EIGRP for IPv6, MSTP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, RIP-1, RIP-2, RIPng, VRRP
Status Indicators
Power
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Expansion Slots
1 (total) / 1 (free) x SD Memory Card
QSFP Slots
10 Gigabit SFP+ (uplink)
Interface Provided
1 x console (micro-USB), 1 x USB 2.0, 12 x 1000Base-T RJ-45 PoE+ - 30 W, 2 x 1000Base-T RJ-45, 2 x 10GBase-X SFP+ uplink
Port Quantity
12
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
1000Base-T
Frequency
50/60 hertz
Power Provided
310 watt
Required Voltage
AC 100-240 volt
Built-in Devices
RFID tag
Encryption
128-bit AES
Humidity Range Storage
5 - 90% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
553,140 Hours
Operating Humidity
5 - 90% (non-condensing)
Capacity
ACL scale entries: 1600, Direct IPv4 routes: 10000, Flexible NetFlow entries: 16000, Indirect IPv4 routes: 4000, IPv4 routes: 14000, IPv4 routing entries: 4000, IPv6 routing entries: 2000, Multicast scale: 1000, PVST instances: 128, QoS scale entries: 1000, STP Virtual Ports for MST: 13000, STP Virtual Ports for PVST: 13000, Virtual networks: 16, VLAN IDs: 4096
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 95.23 Mpps, Packet buffer size: 6 MB, Switching capacity: 120 Gbps
Ports (2nd) Quantity
2
Ports (3rd) Quantity
2
Height
1.7 inch
Height (Rack Units)
1
Weight
6.59 lbs
Width
10.6 inch
Depth
9.6 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, Plug and Play, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - replacement - lifetime - response time: next business day, Technical support - consulting - 90 days
Limited Warranty
Limited Lifetime
