Tech specs
Brand
Aruba
Product Line
HPE Aruba
Model
AP-575 (US) TAA
Manufacturer
Aruba
Compliant Standards
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED 6
Connectivity Technology
Wireless
Data Link Protocols
802.11ax, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data Transfer Rate
3 GBps
Features
4x4:4 MU-MIMO technology, Advanced Cellular Coexistence (ACC), Auto-uplink (auto MDI/MDI-X), Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, Energy-Efficient Ethernet (EEE), HPE SmartRate, Intelligent Power Monitoring (IPM), IPSec Virtual Private Network (VPN), Layer 7 Deep Packet Inspection (DPI), Link Aggregation Control Protocol (LACP), Low Density Parity Check (LDPC), Passpoint Release 2, Policy Enforcement Firewall (PEF), Reset button, Space Time Blocking Code (STBC), Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM)
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE+
Product Type
Wireless access point
Spread Spectrum Method
DSSS, OFDM, OFDMA
Status Indicators
Status
Wireless LAN
802.11a/b/g/n/ac Wave 2/ax
Interface Provided
1 x 1000Base-T - RJ-45, 1 x 2500Base-T (PoE) - RJ-45, 1 x console - USB-C
Power Consumption Operational
25.6 watt
Antenna Form Factor
Internal
Directivity
Omni-directional
Encryption
WPA2
Internet of Things (IoT) Compatible
Yes
Line Coding Format
1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, QPSK
Max Operating Temperature
149 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Operating Humidity
5 - 95% (non-condensing)
Capacity
Wireless clients per Wi-Fi radio: 512
IoT Communications Technology
Bluetooth, Zigbee
Packaged Quantity
1
Ruggedized Design
Outdoor
Service Activation
No
Network Device
Maximum data rate (2.4 GHz): 575 Mbps, Maximum data rate (5 GHz): 4.8 Gbps
Height
10.6 inch
Weight
5.29 lbs
Width
9.1 inch
Depth
9.4 inch
Color Category
Gray
Compliant Standards
CB, cTUVus, EMC 2014/30/EU, EN 60601-1-1, EN 60601-1-2, EN 60950, IEC 60950, ISED, LVD 2014/35/EU, RED 2014/53/EU, UL 2043, UL 60950
ENERGY STAR Certified
No
EPEAT Compliant
No
TAA Compliant
Yes
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
Compatibility Specs
(non-ECC): ¦ HP EliteBook 1050 G1, 735 G5, 735 G6, 745 G5, 745 G6, 755 G5, 820 G4, 830 G5, 830 G6, 830 G8, 840 G3, 840 G4, 840 G5, 840 G6, 840 G8, 840r G4, 845 G7, 850 G3, 850 G4, 850 G5, 850 G6, 855 G7 ¦ HP EliteBook x360 830 G6 ¦ HP ProBook 430 G5, 430 G6, 430 G7, 440 G5, 440 G7, 445r G6, 450 G5, 450 G6, 450 G7, 455r G6, 470 G5, 640 G2, 640 G3, 640 G4, 640 G5, 645 G4, 650 G2, 650 G3, 650 G4, 650 G5 ¦ HP ProBook x360 440 G1 ¦ HP ZBook 14u G4 Mobile Workstation, 14u G5 Mobile Workstation, 14u G6 Mobile Workstation, 15 G3 Mobile Workstation, 15 G4 Mobile Workstation, 15 G5 Mobile Workstation, 15u G3 Mobile Workstation, 15u G4 Mobile Workstation, 15u G5 Mobile Workstation, 15u G6 Mobile Workstation, 15v G5 Mobile Workstation, 17 G3 Mobile Workstation, 17 G4 Mobile Workstation, 17 G5 Mobile Workstation, Studio G3 Mobile Workstation, Studio G4 Mobile Workstation, Studio x360 G5 Mobile Workstation
