Tech specs
Brand
Lenovo
Product Line
Lenovo ThinkCentre M90s Gen 5
Model
12V4
Manufacturer
Lenovo Topseller Desktops
Clock Speed
2.6 GHZ
Cores
14-core
Max Turbo Speed
5 GHZ
Platform Technology
Intel vPro Enterprise
Processor Brand
Intel
Processor Generation
14
Processor Number
14500
Processor Type
Core i5
Processors Installed
1
Total Processor Supported
1
Available Memory Slots
2
Cache Memory Installed
24 megabyte
Configuration Features
2 x 16 GB
Features
Dual channel memory architecture, Unbuffered
Max Memory Supported
128 GB
Memory Slots
4
Memory Speed
4400 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
32 GB
Rated Memory Speed
2200 megahertz
Drive Interface
PCI Express 4.0 x4
Drive Type
No optical drive
Hard Drive Capacity
512 GB
Hard Drive Features
NVM Express (NVMe), TCG Opal Encryption 2
Installed Quantity
1
Interface Class
PCI Express
Optical Drive Type
DVD±RW, DVD-Writer
Optical Drive Type (2nd)
None
SSD Form Factor
M.2 2280
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller Type
Serial ATA
Type
None
Hard Drive Interface Type
SSD
Display Technology
None.
Graphics Controller Model
Intel UHD Graphics 770
Graphics Processor Series
Intel UHD Graphics
Maximum Monitors Supported
4
Touchscreen
No
Video Interfaces
DisplayPort, HDMI
Audio Input Type
None
Compliant Standards
High Definition Audio
Memory Allocation Technology
Shared video memory (UMA)
Interface Provided
1 x audio line-out, 1 x DisplayPort 1.2, 1 x HDMI, 1 x headphones/microphone (1 in front), 1 x LAN (Gigabit Ethernet), 1 x microphone (1 in front), 1 x USB-C 3.2 Gen 2 (1 in front) (data transfer, 15W charging), 2 x DisplayPort 1.4a, 2 x USB 3.2 Gen 2 (2 in front), 6 x USB 3.2 Gen 1 (2 front, 4 rear)
Data Link Protocols
Bluetooth 5.3, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet Controllers
Intel I219-LM
Features
Dual stream (2x2), Wake On LAN (WOL)
Host Interface
M.2 Card
Wireless LAN
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Built-in Devices
Speaker
Chipset Type
Intel Q670
Efficiency
92%
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Small form factor
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
Serial ATA-600
Input Device Type
Keyboard, Mouse
Interface
USB
Interface Type
Serial ATA
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
Mouse Name
Lenovo Calliope Mouse
Operating Humidity
20 - 80%
Controllers Included
1
Country
United States
Printer Product Type
None
Keyboard Localization
English
Keyboard Name
Lenovo Traditional Keyboard
Keys Layout
QWERTY
Localization
English
Manufacturer Form Factor
Small form factor
Packaged Quantity
1
Product Type
Personal computer
Security Slot Type
Kensington security slot
Theft Protection
Padlock loop, Security lock slot (cable lock sold separately)
Expansion Bays
1 (total) / 0 (free) x external 5.25" Slim Line, 1 (total) / 1 (free) x internal 2.5", 1 (total) / 1 (free) x internal 3.5"
Slots
1 (total) / 0 (free) x M.2 Card (for WLAN), 1 (total) / 0 (free) x PCIe 4.0 x16 - low-profile, 1 (total) / 1 (free) x PCIe 3.0 x1 - low-profile, 1 (total) / 1 (free) x PCIe 4.0 x16 - low-profile (x4 mode), 2 (total) / 1 (free) x M.2 Card (for SSD)
Operating System
Windows 11 Pro
Operating System Edition
Windows 11 Pro
Operating System Language
English
Operating System Platform
Windows
Frequency
50/60 hertz
Power Device Type
Power supply
Power Provided
310 watt
Required Voltage
AC 100-240 volt
Color
Black
Color Category
Black
Height
13.4 inch
Weight
11.68 lbs
Width
3.6 inch
Depth
11.7 inch
Compliant Standards
Energy-Related Products (ErP) Lot 3, FIPS 140-2, GREENGUARD, RoHS, TCG Certified
ENERGY STAR Certified
Yes
Energy Star Version
8.0
Environmental Certification
TCO Certified Desktops 9
EPEAT Compliant
Yes
EPEAT Level
EPEAT Gold
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - 3 years - on-site
Limited Warranty
3 Year
