Tech specs
Brand
Sophos
Product Line
Sophos XGS
Model
136w
Manufacturer
Sophos
Hard Drive Capacity
64 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
1
Connectivity Technology
Wired, Wireless
Data Link Protocols
2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
3x3:3 MU-MIMO technology, Deep Packet Inspection (DPI), Firewall protection, Firmware upgradable, Intrusion Prevention System (IPS), SD-WAN support, VPN support, Web threat protection, Zero-Touch Deployment
Form Factor
Desktop
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE+
Product Type
Security appliance
Status Indicators
Link/activity, PoE, Power 1, Power 2, Speed, SSD activity, Status, Wi-Fi
Wireless LAN
802.11a/b/g/n/ac
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interface Provided
1 x management - RJ-45, 1 x micro-USB, 1 x USB 2.0 - Type A, 1 x USB 3.0 - Type A, 10 x 1000Base-T - RJ-45, 2 x 1000Base-X - SFP (mini-GBIC), 2 x 2.5 GBase-T (PoE+) - RJ-45 - 30 W
Frequency
50 - 60 hertz
Power Consumption Operational
65 watt
Power Provided
150 watt
Redundant Power Supply
Optional
Antenna Form Factor
External detachable
Antennas
3
Encryption
TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Concurrent connections: 6400000, New connections per second: 74500, Xstream SSL/TLS concurrent connections: 18432
Country
United States
Device Type
External power adapter
Packaged Quantity
1
Service Activation
No
Network Device
Firewall latency (64-byte UDP): 8 µs, Firewall throughput (IMIX): 4.7 Gbps, Firewall throughput: 11.5 Gbps, IPS throughput: 3.3 Gbps, Threat protection throughput: 1 Gbps, Xstream SSL/TLS inspection: 950 Mbps
Height
1.7 inch
Weight
5.29 lbs
Width
12.6 inch
Depth
8.4 inch
Color Category
White
Compliant Standards
ANATEL, BSMI, CB, CCC, FCC, ISED, KC, NOM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
