Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
601E
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC CP9/NP6
Hard Drive Capacity
240 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
2
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, Gigabit Ethernet
Features
Anti-malware protection, Anti-virus protection, Application filtering, CAPWAP support, Checksum offload support, Content filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), IPv4 support, IPv6 support, Manageable, Routing, Switching, Traffic shaping, VPN support, Web threat protection
Form Factor
Rack-mountable
Network Standard
IPSec, SCTP, TCP/IP, UDP/IP
Product Type
Security appliance
Remote Management
HTTP
Status Indicators
Alarm, HA, Power, Status
Interface Provided
1 x 1000Base-T (HA) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 2 x 10Gb Ethernet - SFP+, 2 x USB 3.0 - Type A, 8 x 1000Base-T - RJ-45, 8 x 1000Base-X - SFP (mini-GBIC)
Frequency
50/60 hertz
Power Consumption Operational
129 watt
Operating System Edition
FortiOS
Encryption
256-bit AES, 256-bit SHA, SSL, TLS 1.2
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 50000, Concurrent SSL VPN users: 5000, Concurrent TCP sessions: 8000000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum number of registered endpoints: 2000, Maximum number of switches: 48, New TCP sessions per second: 450000, Number of FortiAP devices: 512, Number of FortiToken devices: 1000, Virtual domains: 10
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Application control (AVC) throughput: 15 Gbps, CAPWAP throughput: 18 Gbps, Firewall latency (64-byte UDP): 2 µs, Firewall throughput (1518-byte UDP): 36 Gbps, Firewall throughput (512-byte UDP): 36 Gbps, Firewall throughput (64-byte UDP): 27 Gbps, Firewall throughput: 40.5 Mpps, IPS throughput (enterprise traffic mix): 10 Gbps, IPv6 firewall throughput (1518-byte UDP): 36 Gbps, IPv6 firewall throughput (512-byte UDP): 36 Gbps, IPv6 firewall throughput (64-byte UDP): 27 Gbps, NGFW throughput: 9.5 Gbps, SSL inspection throughput: 5500 connections per second, SSL inspection throughput: 8 Gbps, SSL inspection throughput: 800000 concurrent sessions per second, Threat protection throughput: 7 Gbps, VPN throughput (512-bit IPSec): 20 Gbps, VPN throughput (SSL): 7 Gbps
Included Accessories
2 SX SFP transceivers
Height
1.7 inch
Height (Rack Units)
1
Weight
16.53 lbs
Width
17 inch
Depth
15 inch
Color Category
White
Compliant Standards
CB, C-Tick, cUL, FCC Part 15 B Class A, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, IPv6 Ready, UL, USGv6, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Accessories
- CDW Recommends (5) total accessories
- Network Adapters (2) total accessories
View More Accessories
Warranties
1-8 of 299 reviews
Extensive web controls enhance our security posture
What is our primary use case?
We use Fortinet FortiGate for the firewall as well as for the VPN. Any of the users outside the organization use the VPN. Any staff members working outside the office headquarters or our office location use the VPN.
The main aspect that I deal with is URL blocking and web access.
Read more
Ease of deployment and cost-effective but has occasional support challenges
What is our primary use case?
I use Fortinet FortiGate for security as a firewall.
How has it helped my organization?
Fortinet FortiGate helps improve my organization since it's quick and easy to install, and we don't have to call support frequently.
What is most valuable?
It's very similar to a Cisco fire
Read more
Integrated tools enhance network control and security management
What is our primary use case?
We are using Fortinet FortiGate to block or deny malware and to administrate the network to control the traffic inside and outside.
How has it helped my organization?
It has significantly contributed to the effective control and monitoring of the network infrastructure. We could
Read more
A solid firewall with straightforward management and robust capabilities
What is our primary use case?
We primarily use Fortinet FortiGate as endpoint firewalls for our campuses. Nothing too extravagant, just providing access out and limiting access to certain applications and restricting unauthorized access from external sources. I have recently been using it also as the controlle
Read more
Ease of setup and cost-effectiveness but support needs improvement
What is our primary use case?
Fortinet FortiGate is used on three separate sites: one in Tehachapi, one in Simi Valley, California, and one in Memphis, Tennessee. I work in distribution with Fortinet FortiGate.
What is most valuable?
The primary feature I appreciate about Fortinet FortiGate is the ease of se
Read more
Integrated security solution is effective but support can be better
What is our primary use case?
We are using it for the data center firewall and perimeter firewall facing the Internet, which are my main use cases for Fortinet FortiGate.
What is most valuable?
The combined license for the network, the next-generation firewall, and the integration with SD-WAN for all branche
Read more
Meets various needs and it's cost-effective and simple
What is our primary use case?
We are using Fortinet FortiGate for enterprises. We are a partner of Fortinet.
How has it helped my organization?
Its features are very good for the price. Their support is also very good. A lot of expertise is available in the market in terms of engineers.
What is most valuabl
Read more
User-friendly interface simplifies security settings and improves detection efficiency
What is our primary use case?
I used Fortinet FortiGate to protect some perimeters, and I used it a lot for detection, filtering, domain control, and security functions and features.
I worked for a company that used Fortinet FortiGate to provide services to many customers across various industries and through
Read more
