Tech specs
Brand
ASUS
Product Line
ASUS
Model
PRIME H770-PLUS D4
Manufacturer
Asus Components
Processor Socket
LGA1700 Socket
Processors Installed
0
Total Processor Supported
1
Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Max Memory Supported
128 GB
Memory Slots
4 DIMM slots
Mainboard Supported RAM
DDR4 SDRAM
Supported Memory Speed
2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz, 3333 MHz (O.C.), 3400 MHz (O.C.), 3466 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 4000 MHz (O.C.), 4266 MHz (O.C.), 4400 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 5000 MHz (O.C.), 5066 MHz (O.C.)
Storage Interfaces
PCIe 4.0 -connectors: 2 x M.2, SATA-600 / PCIe 4.0 -connectors: 1 x M.2, SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
Data Link Protocols
2.5 Gigabit Ethernet, Ethernet, Gigabit Ethernet
Network
2.5 Gigabit Ethernet
Expansion Slots
1 x CPU, 1 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot), 1 x M.2 socket (Key E), 1 x PCIe 5.0 x16, 2 x M.2 socket (2242/2260/2280 M.2 Key M slot), 2 x PCIe 3.0 x1, 2 x PCIe 4.0 x16 (x4 mode), 4 x DIMM 288-pin
Interface Provided
1 x audio line-in - mini-jack, 1 x audio line-out - mini-jack, 1 x DisplayPort, 1 x HDMI, 1 x LAN (2.5Gigabit Ethernet), 1 x microphone - mini-jack, 1 x USB-C 3.2 Gen 2, 2 x USB 2.0, 2 x USB 3.2 Gen 2, 3 x USB 3.2 Gen 1
Internal Interfaces
1 x audio - header, 1 x serial - header, 1 x SPDIF out - header, 1 x SPI - header, 1 x Thunderbolt - header, 3 x USB 2.0 - header, 4 x USB 3.2 Gen 1 - header
Storage
M.2 socket, Serial ATA-600 (RAID)
Storage Ports
4 x SATA-600 (RAID), 3 x M.2
USB & FireWire
USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C 3.2 Gen2
USB & FireWire Ports Configuration (Active)
1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 2 + 3 USB 3.2 Gen 1 + 2 x USB 2.0
USB & FireWire Ports Configuration (Headers)
4 x USB 3.2 Gen 1 + 3 x USB 2.0
Type
Graphics adapter (CPU required)
Audio Output
High Definition Audio (8-channel)
Compliant Standards
High Definition Audio
Output Type
Sound card
Included Software
Armoury Crate, ASUS AI Suite III, ASUS AURA Creator, ASUS CPU-Z, ASUS Fan Xpert 2+, Norton 360 Deluxe (60 days trial), PC Cleaner, WinRAR
Chipset Type
Intel H770
Compatible Processors Comments
Supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron
Form Factor (Motherboard)
ATX
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Supported RAM (Registered or Buffered)
Unbuffered
Supported RAM Integrity Check
Non-ECC
BIOS Features
ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode, UEFI BIOS
BIOS Type
AMI
Hardware Features
ASUS 5X Protection III, ASUS Aura Sync, ASUS DIGI+ VRM, ASUS EZ DIY, ASUS OptiMem, ASUS ProCool, ASUS Q-Design, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, CrashFree BIOS 3, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, LANGuard, Overvoltage protection, Preboot eXecution Environment (PXE), Q-DIMM, Q-LED Core, Q-Slot, VRM heatsink design, Windows 11 compatible
Packaged Quantity
1
Product Type
Motherboard
RAID Features
Intel Rapid Storage Technology
Sleep/Wake Up
Wake on LAN (WOL), Wake on PME
Cables
2 x Serial ATA cable
Included Accessories
1 x M.2 rubber package, 2 x M.2 screw package, IO shield
Width
12 inch
Depth
9.6 inch
Compliant Standards
DisplayPort 1.4
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
