Tech specs
Brand
ATEN
Product Line
ATEN
Model
CS1142H4C
Edition
PSD PP v4.0 Compliant
Manufacturer
Aten Technologies
Compliant Standards
PSD PP v4.0
Features
4K resolution support, Anti-tampering protection, Call Admission Control (CAC), Chassis intrusion detection, Data Channel Isolation, Event log, Input selection buttons, Metal housing, Reset button, Rugged, Unidirectional Data Flow
Form Factor (Hubs & Switches)
Desktop
Ports
2
Product Type
KVM / audio switch
Status Indicators
Key lock, Online, Power, Video
Subcategory
KVM
Switching Type
KVM
Interface Provided
1 x audio output mini-jack console, 1 x keyboard (USB) Type A console, 1 x mouse (USB) Type A console, 1 x RJ-11, 1 x USB Type A common access card (CAC), 2 x audio mini-jack, 2 x HDMI console, 2 x keyboard (USB) / mouse (USB) Type B, 2 x USB Type B common access card (CAC), 4 x HDMI
Port Quantity
2
Port Type
KVM / audio
KVP Max Resolution
3840 x 2160
Frequency
50/60 hertz
Output Current
1 ampere
Power Consumption Operational
5.4 watt
Required Voltage
AC 100-240 volt
Built-in Devices
LED panel
KVM V-Sync Rate At Max Resolution
60 Hz
Local Users Supported
1 local user
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
140 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Operating Humidity
0 - 80% RH (non-condensing)
Device Type
Internal power supply
Keyboard
USB
Packaged Quantity
1
Height
2.6 inch
Weight
4.65 lbs
Width
13.2 inch
Depth
6.5 inch
Color Category
Black
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
