Tech specs
Brand
Axis
Product Line
AXIS
Model
P1468-LE
Manufacturer
Axis Communications
Flash Memory Installed
8 GB
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
2 GB
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, CDP, CIFS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IGMPv2, IGMPv3, IPv4, IPv6, LLDP, MQTT, NTP, QOS, RTCP, RTP, RTSP, SFTP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, SRTP, SSH, Syslog, TCP/IP, TLS, UDP/IP, UPnP, USGv6, Zeroconf
Connectivity Technology
Wired
Ports
Audio line-in/microphone - 3.5 mm jack, LAN/power - RJ-45
Image Sensor Size
1/1.2"
Image Sensor Type
CMOS
Audio Support
Yes
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
160 x 90, 3840 x 2160
Max Frame Rate
30 frames per second
Max Video Resolution
3840 x 2160
Motion Detection
Yes
Shutter Speed (Max)
1/66500 second (time unit)
Shutter Speed (Min)
2 second (time unit)
Video Capture
160 x 90 @ 30 fps, 3840 x 2160 @ 30 fps
Video Modes
3840/30p
Camera Type
Network surveillance camera
Night Vision
Yes
Power Consumption Operational
12.95 watt
Software Type
Windows decoder 1-user license
Angular Field of View (H, Max, Degree)
108
Angular Field of View (H, Min, Degree)
49
Angular Field of View (V, Max, Degree)
58
Angular Field of View (V, Min, Degree)
27
Auto Iris Control
P-Iris
Camera Iris
Auto iris
Focal Length Control
Vari-focal
Focus Modes
Automatic
Indoor/Outdoor
Outdoor
Infrared Distance
131 ft
Infrared LEDs
Yes
Lens Aperture
F/1.6
Max Focal Length
12.9 millimetre
Max Operating Temperature
140 degree Fahrenheit
Min Focal Length
6.2 millimetre
Min Operating Temperature
-40 degree Fahrenheit
Minimum Illumination
0 lux - IR, 0.01 lux - B&W - F1.6 - 50 IRE, 0.07 lux - color - F1.6 - 50 IRE
Operating Humidity
10 - 100%
Optical Zoom
2.08
Protection
Dustproof / waterproof / vandal-proof
Sensor Size (metric)
21.2 mm (1/1.2")
Video Formats
H.264, H.265, MJPEG, MPEG-4 AVC
Video Input
Color
Alarm Input Quantity
1
Alarm Output Quantity
1
Features
AXIS Video Hosting System (AVHS), Brightness control, Contrast control, Digital image rotation, Digital PTZ function, Exposure control, Forensic WDR, Image mirror, Infrared-cut filter, IP address filtering, IR Corrected lens, Lightfinder technology, ONVIF (Profile G) support, ONVIF (Profile S) support, OptimizedIR, Password protection, Privacy Mask Function, Progressive scanning, Saturation control, Sharpness control, White balance, Zipstream technology
Packaged Quantity
1
Included Accessories
Connector kit, Drill hole template, Mounting bracket, Weathershield
Height
5.2 inch
Weight
2.65 lbs
Width
5.2 inch
Depth
11 inch
Color
White
Color Category
White
Compliant Standards
EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC 62471, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, ISO 21207 method B, NEMA TS-2, NIST SP500-267, RCM Class A, VCCI Class A
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
