Tech specs
Brand
Axis
Product Line
AXIS
Model
Q3538-SLVE
Manufacturer
Axis Communications
Flash Memory Installed
8194 megabyte
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
2048 megabyte
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, Bonjour, CDP, CIFS, DDNS, DHCP, DNS, EAP, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, MQTT, NTP, QOS, RTCP, RTP, RTSP, SFTP, SIP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SRTP, SSH, Syslog, TCP/IP, TLS, UDP/IP, UPnP, USGv6, Zeroconf
Connectivity Technology
Wired
Ports
Audio line out - 3.5 mm jack, Audio line-in/microphone - 3.5 mm jack, Digital output - terminal block, LAN/power - RJ-45
Image Sensor Size
1/1.2"
Image Sensor Type
PS RGB CMOS
Tilt
-43 to +80
Audio Formats
AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS
Audio Support
Yes
Audio Support Features
Two-way audio capability
Camera Mechanical Design
Fixed
Max Frame Rate
60 frames per second
Max Video Resolution
3840 x 2160
Motion Detection
Yes
Panning Range (degree)
-180 to +180
Shutter Speed (Max)
2 second (time unit)
Shutter Speed (Min)
1/66500 second (time unit)
Video Modes
4K
Camera Mount Type
Wall mount
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
DC 10 - 28 V / PoE Plus Class 4
Power Consumption Operational
9 watt
Software Type
Windows decoder 1-user license
Angular Field of View (H, Max, Degree)
103
Angular Field of View (H, Min, Degree)
48
Angular Field of View (V, Max, Degree)
56.4
Angular Field of View (V, Min, Degree)
27.4
Auto Iris Control
P-Iris
Focal Length Control
Vari-focal
Form Factor
Dome
Indoor/Outdoor
Outdoor
Infrared Distance
131 ft
Infrared LEDs
Yes
Lens Aperture
F/1.6-2.9
Lens Mount
M25 mount
Max Focal Length
12.9 millimetre
Max Operating Temperature
140 degree Fahrenheit
Min Focal Length
6.2 millimetre
Min Operating Temperature
-58 degree Fahrenheit
Minimum Illumination
0 lux - B&W - F1.6 - 50 IRE, 0.07 lux - color - F1.6 - 50 IRE
Operating Humidity
10 - 100% RH (condensing)
Optical Zoom
2
Protection
Vandal / weatherproof
Sensor Size (metric)
21.2 mm (1/1.2")
Total Pixels
8,000,000 pixels
Video Formats
AVC, H.264, H.265, HEVC, MJPEG, MPEG-4 Part 10, MPEG-H Part 2
Video Input
Color
Features
180° image rotation, 270° image rotation, 90° image rotation, Aluminum housing, Auto gain control, Axis device ID, Axis Edge Vault, Barrel distortion correction, Brightness control, Brute force delay protection, Centralized certificate management, Compression, Contrast control, Control queue, Corridor mode, Deep learning processing unit (DLPU), Defogging, Digest authentication, Digital PTZ function, Electronic image stabilization, Exposure mode, Exposure zone, Forensic WDR, Guard tour, Heater, HTTPs encryption, Human Detection, Image mirror, Image overlay, Infrared cut filter, Infrared sensor, IP address filtering, Lightfinder 2.0 technology, Line Crossing Detection, Object enter area detection, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, OptimizedIR, Password protection, P-Iris control, Plastic housing, Polygon privacy mask, Privacy Mask Function, Remote focus, Remote zoom, Saturation control, Secure Boot, Secure keystore, Sharpness control, Signed firmware, Signed video, Text overlay, Tone mapping, Trusted Platform Module (TPM), User access log, Vehicle Detection, Video streaming indicator, White balance, Zipstream technology
Localization
Chinese (Simplified), Chinese (Traditional), English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish
Packaged Quantity
1
Included Accessories
Cable gasket, Conduit adapter, Connector guard, Drill hole template, Mounting bracket, Resistorx L-key, Terminal block connectors, Weathershield
Height
4.9 inch
Weight
4.63 lbs
Width
7.2 inch
Depth
7.2 inch
Color
NCS S 1002-B, White
Color Category
White
Compliant Standards
AES-256, AS/NZS CISPR 32 Class A, CAN ICES-3 Class A, CAN/CSA-C22.2 No. 60950-22, CAN/CSA-C22.2 No. 62368-1, CISPR 35, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, FIPS 140-2 Level 2, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC 62471, IEC/EN 60529 IP66, IEC/EN 62262 IK10+, IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, IEEE 802.1x, IEEE 802.3bt Type 2, IP6K9K, IS13252, KS C 9832 Class A, KS C 9835, NEMA TS-2, NEMA250 Type 4X, NIST SP500-267, NMB-3 Class A, PVC-free, VCCI Class A
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
