Tech specs
Brand
Axis
Product Line
AXIS
Model
Q6010-E 60Hz
Manufacturer
Axis Communications
Flash Memory Installed
512 megabyte
Memory Cards Supported
SD Memory Card, SDHC Memory Card, SDXC Memory Card
RAM Installed
2048 megabyte
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, Bonjour, CIFS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, QOS, RTCP, RTP, RTSP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, SSH, SSL, TCP/IP, TLS, UDP/IP, UPnP
Connectivity Technology
Wired
Ports
LAN - RJ-45, LAN/power - RJ-45
Image Sensor Size
1/2.5"
Image Sensor Type
RGB CMOS
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
2592 x 1944, 320 x 240
Max Frame Rate
20 frames per second
Max Video Resolution
2592 x 1944
Motion Detection
Yes
Shutter Speed (Max)
1/32500 second (time unit)
Shutter Speed (Min)
1/20 second (time unit)
Camera Type
Network surveillance camera
Low Voltage Power
PoE
Power Consumption Operational
22 watt
Software Type
Windows decoder 1-user license
Angular Field of View (H, Min, Degree)
360
Angular Field of View (V, Min, Degree)
84
Camera Iris
Fixed iris
Focal Length Control
Fixed focal
Focus Modes
Automatic
Form Factor
Dome
Indoor/Outdoor
Outdoor
Lens Aperture
F/2.0
Max Focal Length
2.8 millimetre
Max Operating Temperature
165.2 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Minimum Illumination
0.03 lux - B&W - F2.0 - 50 IRE, 0.4 lux - color - F2.0 - 50 IRE
Operating Humidity
10 - 100%
Sensor Size (metric)
10.2 mm (1/2.5")
Total Pixels
4 x 5,000,000 pixels
Video Formats
H.264, H.265, HEVC, MPEG-4 AVC
Video Input
Color
Country
Brazil, Japan, Korea, United States
Features
360° monitoring, Advanced de-warping technology, Brightness control, Color control, Contrast control, Digest authentication, Exposure control, Exposure zone, Image mirror, Image overlay, Lens preset positioning, NAS-Ready, Noise Reduction, Password protection, Pixel Counter Support, Privacy Mask Function, PTZ ready, Sharpness control, Variable Bit Rate (VBR), Video Motion Detection Technology, White balance, Wide Dynamic Range (WDR), Zipstream technology
Packaged Quantity
1
Included Accessories
Bayonet screws, Q60-E adapter
Height
7.9 inch
Weight
9.92 lbs
Width
15.6 inch
Depth
15.6 inch
Color Category
White
Compliant Standards
AS/NZS CISPR 32 Class A, CAN/CSA C22.2 No. 60950-22, CAN/CSA-C22.2 No. 62368-1, EAC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 62236-4, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, KCC KN32 Class A, KN35, NEMA TS-2, NEMA250 Type 4X, NIST SP500-267, RCM, VCCI Class A
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
