Tech specs
Brand
Barco
Product Line
Barco Coronis Fusion
Model
6MP MDCC-6530
Manufacturer
Barco
Interfaces
2 x DisplayPort 1.2, 3 x USB 2.0 downstream, DisplayPort (MST), USB 2.0 upstream
Backlight Life
40,000 Hours
Display Image Brightness
1050 candela per square metre
Display Contrast Ratio
2000:1
Display Position Adjustments
Height, Swivel, Tilt
Display Screen Coating
Anti-reflective
Display Screen Technology
TFT active matrix
Display Type
LED-backlit LCD monitor
Features
30-bit lookup table, Ambient Light Compensation (ALC), Ambient light sensor, Ambient lighting, Color Imaging, DICOM calibrated, Glass cover, Gray imaging, Grayscale Viewing, I-Guard, Per Pixel Uniformity (PPU)
Form Factor
Desktop
Height Adjustment
3.9 inch
Horizontal Viewing Angle
178
Input Signal
2xDisplayPort
Interface
DisplayPort
Medical Display Type
Color
Native Resolution
3280 x 2048
Pixel Pitch
0.1995 millimetre
Response Time
18 millisecond
Screen Size
30.4 inch
Screen Size (metric)
77.2 centimetre
Swivel Angle
60
TFT Technology
IPS
Tilt Angle
-5/+25
Touchscreen
No
Typical Response Time
18 ms (tr - tf)
Vertical Viewing Angle
178
Monitor Aspect Ratio
16:10
Display Backlight Technology
LED backlight
Frequency
50/60 hertz
Power Consumption (Typical)
80 watt
Sleep-Mode Power Consumption
0.5 watt
Software Type
Barco MediCal QAWeb
Built-in Devices
USB 2.0 hub
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 85% (non-condensing)
Built-in USB Hub
Yes
Flat Panel Mount Interface
100 x 100 mm
Medical
Yes
Packaged Quantity
1
Resolution
6MP
TV Tuner Presence
No
Cables
1 x DisplayPort cable, 1 x USB cable
Comments
With stand
Dimensions Details
With stand - width: 28.1 in - depth: 9.4 in - height: 24.6 in - weight: 39 lbs, Without stand - width: 28.1 in - depth: 2.9 in - height: 19.2 in - weight: 28.9 lbs
Height
24.6 inch
Weight
39.02 lbs
Width
28.1 inch
Depth
9.4 inch
Color Category
Black
Compliant Standards
ANSI/AAMI ES60601-1:2005 + R1:2012, BIS, BMSI, CCC, China RoHS, CSA C22.2 No. 60601-1:2014 3rd Edition, EAC, EMI, EN 60601-1:2006 + A1:2013 + A12:2014, EN 60601-1-2:2015, EN 60950-1:2006+A1:2010+A2:2013+A11:2009+A12:2011, EU RoHS, FCC Part 15 Class B, FDA 510k, ICES-001 level B, IEC 60601-1:2005 + A1:2012, IEC 60601-1-2:2014, IEC 60950-1:2005 + A1:2009, KC, MDD 93/42/EEC, MDD 93/42/EEC; A1:2007/47/EC class II, PSE Mark, REACH, VCCI, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
Standby Power Consumption
0.5 watt
