Tech specs
Brand
Barco
Product Line
Barco Eonis
Model
MDRC-2424
Manufacturer
Barco
Interfaces
2 x USB 2.0 downstream (Type A), DisplayPort, DVI-I, HDMI, USB 2.0 upstream (Type B)
Display Image Brightness
600 candela per square metre
Color Support
16.7 million colors (24-bit)
Display Contrast Ratio
1000:1
Display Position Adjustments
Height, Pivot (rotation), Tilt
Display Screen Technology
Advanced Dimension Switch (ADS)
Display Type
LCD monitor
Features
Color Imaging, Consistency sensor, DICOM Compliant, Glass cover, Gray imaging, Picture Archiving and Communication Systems (PACS)
Form Factor
Desktop
Height Adjustment
4.3 inch
Horizontal Viewing Angle
178
Input Signal
HDMI, DVI-D, DisplayPort
Interface
DisplayPort, DVI, HDMI
Medical Display Type
Color
Native Resolution
1920 x 1200
Pixel Pitch
0.27 millimetre
Response Time
14 millisecond
Rotation Angle
90
Screen Size
24 inch
Screen Size (metric)
60.96 centimetre
Tilt Angle
-5/+22
Touchscreen
No
Typical Response Time
14 ms ((tr + tf)/2)
Vertical Viewing Angle
178
Video Format
WUXGA
Monitor Aspect Ratio
16:10
Frequency
50/60 hertz
Power Consumption (Off Mode)
0.3 watt
Power Consumption (Typical)
35 watt
Required Voltage
AC 100-240 volt
Software Type
Barco QAWeb Enterprise
Built-in Devices
USB 2.0 hub
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 80% (non-condensing)
Built-in USB Hub
Yes
Features
Earth clamp, Portrait / landscape mode, Protective cover, Security lock slot (cable lock sold separately)
Flat Panel Mount Interface
100 x 100 mm
Image Color Disclaimer
The displayed product image may be a different color
Medical
Yes
Packaged Quantity
1
Resolution
2MP
Security Slot Type
Kensington security slot
TV Tuner Presence
No
Cables
1 x DisplayPort cable, 1 x USB cable
Monitor Accessories Included
Power adapter
Comments
With stand (landscape orientation, highest position)
Dimensions Details
With stand (landscape orientation, highest position) - width: 22.4 in - depth: 7.9 in - height: 20.9 in - weight: 17.6 lbs, With stand (landscape orientation, lowest position) - width: 22.4 in - depth: 7.9 in - height: 16.6 in - weight: 17.6 lbs, With stand (portrait orientation, highest position) - width: 15.1 in - depth: 7.9 in - height: 24.8 in - weight: 17.6 lbs, With stand (portrait orientation, lowest position) - width: 15.1 in - depth: 7.9 in - height: 22.7 in - weight: 17.6 lbs, Without stand (landscape orientation) - width: 22.4 in - depth: 2.6 in - height: 15.1 in - weight: 12.8 lbs, Without stand (portrait orientation) - width: 15.1 in - depth: 2.6 in - height: 22.4 in - weight: 12.8 lbs
Height
20.9 inch
Weight
17.64 lbs
Width
22.4 inch
Depth
7.9 inch
Color
RAL 9003, White
Color Category
White
Compliant Standards
ANSI/AAMI ES60601-1:2005 + R1:2012 + R2:2021, BIS, CAN/CSA C22.2 No. 60601-1:14, Canada Health, CCC, CECP, China RoHS, Class I Medical Device, DEMKO, EN 60601-1:2006 + A1:2013 + A12:2014 + A2:2021, EN IEC 62368-1:2020+A11:2020, FCC Part 15 Class B, FDA 510k (Class I), GB 17625.1-2012, GB 4943.1-2022, GB/T 9254.1-2021, Halogen-free, ICES-003 Level B, IEC 60601-1:2005 + A1:2012 + A2:2020, IEC 60601-1-2:2014 + A1:2020, IEC 60601-1-2:2015 + A1:2021, IEC 62368-1:2018, KC, REACH, RoHS, UKCA, UL, VCCI, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Standby Power Consumption
0.3 watt
