Tech specs
Brand
Barco
Product Line
Barco
Model
MDSC-8532
Manufacturer
Barco
Interfaces
2 x HDMI (HDCP 1.4), 3G-SDI (input loop through), DisplayPort 1.2 (HDCP 1.4), DVI (FHD input (upscaled to 4K)), USB, USB-B
Display Image Brightness
850 candela per square metre
Color Support
1 billion colors
Display Contrast Ratio
1350:1
Display Screen Coating
Anti-fingerprint, Anti-reflective
Display Type
LED-backlit LCD monitor
Features
Cable management cover, Color Calibrated, DICOM Compliant, Failover mode, Fanless cooling, Mirror image flip, Picture by picture, Picture-in-Picture, Slim Design, UHD Upscale, Zoom
Horizontal Viewing Angle
178
Image Color Temperature
5600K, 6500K, 7600K, 9300K
Input Signal
DisplayPort, DVI-D, 3G-SDI, 2xHDMI
Interface
3G-SDI, DisplayPort, DVI, HDMI
Medical Display Type
Color
Native Resolution
3840 x 2160
Pixel Pitch
0.1845 millimetre
Response Time
18 millisecond
Screen Size
32 inch
Screen Size (metric)
81.3 centimetre
TFT Technology
AMLCD
Touchscreen
No
Typical Response Time
18 ms (tr - tf)
Vertical Viewing Angle
178
Video Format
4K
Viewable Size
32 inch
Viewable Size (metric)
81.3 centimetre
Monitor Aspect Ratio
16:9
Display Backlight Technology
LED backlight
Power Consumption (On mode)
100 watt
Input Device Type
5 front panel capacitive touch programmable keys, 5 rear panel membrane keys
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 85% (non-condensing)
Features
IP45 front protection
Flat Panel Mount Interface
100 x 100 mm
Medical
Yes
Packaged Quantity
1
TV Tuner Presence
No
Height
18.9 inch
Weight
26.46 lbs
Width
30.2 inch
Depth
3.1 inch
Color
White
Color Category
White
Compliant Standards
ABNT NBR IEC 60601-1:2010 + Emenda 1:2016, ABNT NBR IEC 60601-1-2:2017, ABNT NBR IEC 60601-1-6:2011 + Emenda 1:2020, ABNT NBR IEC 60601-1-9:2010 + Emenda 1:2014, ANSI/AAMI ES60601-1:2005 + R1:2012, BIS, CAN/CSA-C22.2 No. 60601-1:2014, CCC, Class I Medical Device, C-UL-US, DEMKO, EN 60601-1:2006 + A1:2013 + A12:2014, EN 60601-1-2:2015 + A1:2021, FCC CFR47 Part 15 B Class B, GB 17625.1-2012, GB 4943.1-2011, GB/T9254-2008, ICES-003 Class B, IEC 60601-1:2012 Edition 3.1, IEC 60601-1-2:2014 + A1:2020, IEC 60950-1:2005, INMETRO, IS13252-1 (2010), REACH, RoHS 3, UL 60950-1 Second Edition, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
