Tech specs
Brand
Cisco
Product Line
Cisco ATA
Model
191
Manufacturer
Cisco Systems
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet
Features
AES encryption, Cisco Discovery Protocol, DHCP client, DiffServ support, Dual image support, Full duplex mode, Internet Control Message Protocol (ICMP), IPv6 support, LLDP support, Quality of Service (QoS), Reset button, Secure Boot, SNTP support, Syslog support, Type of Service (ToS), VLAN Tagging
Form Factor
Wall Mountable
IP Telephony Features
Adaptative jitter buffer, Call forwarding, Call hold, Call transfer, Call waiting, Caller ID, Comfort noise generation (CNG), Echo cancellation, Silence suppression, Voice activity detection (VAD)
Network Standard
ARP, DHCP, RTCP, RTP
Product Type
VoIP phone adapter
Remote Management
HTTP, HTTPS, SSH, TFTP
Status Indicators
Phone, Power
Interface Provided
1 x 100Base-TX - RJ-45, 2 x FXS - RJ-11
Power Consumption Operational
5 watt
Encryption
AES
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
300,000 Hours
Operating Humidity
10 - 90% (non-condensing)
Voice Codec
G.711, G.711a, G.711u, G.729a, G.729ab, T.38
Device Type
External power adapter
Packaged Quantity
1
Telephony Interfaces
2 phone (FXS)
VoIP
Yes
VoIP Protocols
RTCP, RTP, SIP, SRTP
Height
3.9 inch
Weight
4.66 ounce
Width
3.9 inch
Depth
1.1 inch
Color Category
Gray
Compliant Standards
ANSI C63.4-2014, AS/NZS 60950-1:2015, AS/NZS CISPR32:2015 Class B, CAN/CSA C22.2 No. 60950 Second Edition, Directive 2014/30/EU, Directive 2014/35/EU, EN 55024:2010+A1:2015, EN 55032:2015 Class B, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, EN 61000-4.4:2012, EN 61000-4-11:2004, EN 61000-4-2:2009, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-5:2014, EN 61000-4-8:2010, FCC Part 15 B, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, UL 60950 Second Edition
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
