Tech specs
Brand
Cisco
Product Line
Cisco Business
Model
240AC
Manufacturer
Cisco Systems
Flash Memory Installed
256 megabyte
RAM Installed
1 GB
Compliant Standards
IEEE 802.11a, IEEE 802.11ac Wave 1, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Connectivity Technology
Wireless
Data Link Protocols
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
4x4 MU-MIMO technology, 802.1x authentication, Authentication, Authorization and Accounting (AAA), Beamforming technology, Ceiling mountable, DFS support, Manageable, Mesh networking, RADIUS support, VLAN support, Wi-Fi Multimedia (WMM) support
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE+
Product Type
Wireless access point
Status Indicators
Status
Wireless LAN
802.11a/b/g/n/ac Wave 2
Interface Provided
2 x 1000Base-T (PoE+) - RJ-45
Power Consumption Operational
13.2 watt
Antenna Form Factor
Internal
Antennas
2
Directivity
Omni-directional
Encryption
AES, PEAP, TLS, TTLS, WPA2, WPA3
Max Operating Temperature
158 degree Fahrenheit
Min Operating Temperature
-22 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Authentication Method
EAP-FAST, Extensible Authentication Protocol (EAP), MS-CHAP v.2, RADIUS
Capacity
VLANs supported: 16, Wireless clients per Wi-Fi radio: 200, Wireless clients: 400
Packaged Quantity
1
Service Activation
No
Network Device
Maximum data rate (5 GHz): 1733 Mbps
Height
1.5 inch
Weight
15.17 ounce
Width
7 inch
Depth
7 inch
Color Category
White
Compliant Standards
ARPANSA, AS/NZS 2772, AS/NZS 4268:2017, AS/NZS 60950-1, AS/NZS CISPR 32:2015, CAN/CSA-C22.2 No. 60950-1, CECP, CISPR 24:2010, CISPR 32:2015, CNS 13438, EN 300 328 V2.1.1, EN 301 489-1 V2.1.1:2017, EN 301 489-17 V3.1.1 (2017), EN 301 893 V2.1.1, EN 50385, EN 55032:2012+AC:2013 Class A, EN 55032:2015, EN 55035, EN 60601-1-1, EN 60950-1, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 62209-1, EN 62209-2, EN55024, ICES-003 issue 6 Class B, IEC 60950-1, KN 489-1, KN 489-17, KN 61000-3-2, KN 61000-3-3, KN32, LP0002, NRCAN, QCVN, RSP-100, RSS-102, RSS-247, RSS-GEN, SRRC, TCVN 7189, UL 2043, UL 60950-1, VCCI V-3
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - replacement - lifetime
Limited Warranty
Lifetime Limited
