Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200
Edition
Essential Edition
Manufacturer
Cisco Systems
Flash Memory Installed
4 GB
RAM Installed
4 GB
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
Control plane protection (CoPP), DNA support, Embedded Event Manager (EEM), First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Sampled NetFlow, Switched Port Analyzer (SPAN)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
Manageable
Yes
PoE Budget
740 watt
Ports
48
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
NETCONF, RESTCONF
Routing Protocol
EIGRP, EIGRP for IPv6, IS-IS, MSTP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, RIP-1, RIP-2, RIPng, VRRP
Smart
Yes
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
48 x 1000Base-T RJ-45 PoE+ - 30 W
Port Quantity
48
Port Type
10/100/1000 (PoE+)
Hot-Plug
Hot-plug
Power Provided
1000 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Required Voltage
AC 100-240 volt
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
375,570 Hours
Operating System Required
Cisco IOS XE 16.9.2 or later
Capacity
ACL scale entries: 16000, Direct IPv4 routes: 10000, Flexible NetFlow entries: 16000, Indirect IPv4 routes: 4000, IPv4 routes: 14000, IPv4 routing table entries: 4000, IPv6 routing table entries: 2000, MAC addresses: 32000, Multicast scale: 1000, Packet buffer size: 6 MB, Virtual networks: 4, VLAN IDs: 1000
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 261.9 Mpps, Switching capacity: 176 Gbps, Wireless bandwidth: up to 48 Gbps
Height
13.8 inch
Weight
12.13 lbs
Width
17.5 inch
Depth
1.7 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day, Technical support - phone consulting - 90 days
Limited Warranty
Limited Lifetime
