Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
IE3100 Rugged Series
Manufacturer
Cisco Systems
RAM Installed
4 GB
Compliant Standards
IEEE 1588v2, IEEE 1613, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
Features
Layer 2 switching, Media Redundancy Protocol (MRP), Resilient Ethernet Protocol (REP)
Form Factor (Hubs & Switches)
DIN rail mountable
Ports
10
Product Type
Switch
Remote Management
DHCP, Modbus, NETCONF, RESTCONF, SNMP
Subcategory
Network hubs and switches
Interface Provided
1 x console RJ-45, 1 x micro-USB mini-USB, 2 x 1000Base-TX, 8 x 10/100/1000 Base-T RJ-45
Port Quantity
8
Port Type
10/100/1000
Ports Type (2nd)
Combo Gigabit
Output Current
2 ampere
Provided Voltage
12 - 48 volt
Max Operating Temperature
167 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
854,560 Hours
Operating Humidity
5 - 95% (non-condensing)
Capacity
IGMP groups: 512, IPv4 unicast indirect routes: 2000, Queues per port (egress): 8, STP instances: 128, Unicast MAC addresses: 8000, VLAN groups: 256
Device Type
External power adapter
Packaged Quantity
1
Ports (2nd) Quantity
2
Height
4.3 inch
Weight
30.33 ounce
Width
5 inch
Depth
3 inch
Color Category
Black
Compliant Standards
AS/NZS CISPR 24, AS/NZS CISPR 32 Class A, BSMI CNS13438, Class A, China RoHS, CSA C22.2 No. 213, EN 50121-3-2, EN 50121-4, EN 55032 Class A, EN 61131-2, EN 61326, EN 61373, EN55024, EU RoHS, FCC 47 CFR Part 15 B Class A, ICES-003 Class A, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-3, IEC 60068-2-30, IEC 60068-2-52, IEC 60068-2-6, IEC 60068-2-60, IEC 60068-2-64, IEC 60079-0, IEC 60079-15, IEC 60079-7, IEC 62368-1, IEC/EN 61000-4-10, IEC/EN 61000-4-29, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-9, IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-4, IEC/EN 61010-2-201, IEC/EN/EN61000-4-2, IP30, ISO 12944-6, KN32/35, Class A, NEMA TS-2, ODVA Class 2 Thin, RCM, RFC768, RFC783, RFC791, RFC792, UL 121201, UL/CSA 60079-0, UL/CSA 61010-2-201, UL/CSA 62368-1, UL/CSA60950-1, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited hardware warranty - 5 years
Limited Warranty
5 Year
