Tech specs
Brand
Dell
Product Line
OptiPlex
Model
7020 (version 2024)
Manufacturer
Dell Smart Select Desktops
Clock Speed
1.7 GHZ
Cores
14-core
Max Turbo Speed
4.8 GHZ
Processor Brand
Intel
Processor Generation
14
Processor Number
14500T
Processor Type
Core i5
Processors Installed
1
Total Processor Supported
1
Available Memory Slots
1
Cache Memory Installed
24 megabyte
Configuration Features
1 x 16 GB
Data Integrity Check
Non-ECC
Max Memory Supported
64 GB
Memory Slots
2
Memory Speed
5600 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
16 GB
Rated Memory Speed
5600 megahertz
Drive Type
No optical drive
Hard Drive Capacity
512 GB
Hard Drive Features
Class 35, NVM Express (NVMe)
Installed Quantity
1
Interface Class
PCI Express
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
SSD Form Factor
M.2 2230
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Type
None
Hard Drive Interface Type
SSD
Display Technology
None.
Graphics Controller Model
Intel UHD Graphics 770
Graphics Processor Series
Intel UHD Graphics
Touchscreen
No
Video Interfaces
DisplayPort, HDMI
Compliant Standards
High Definition Audio
Memory Allocation Technology
Shared video memory (UMA)
Interface Provided
1 x DisplayPort 1.4a, 1 x DisplayPort/USB-C (Power Delivery), 1 x HDMI, 1 x headphones/microphone (1 in front), 1 x LAN (Gigabit Ethernet), 1 x USB-C 3.2 Gen 2 (1 front), 2 x USB 2.0 (2 rear) (one of them supports SmartPower On), 3 x USB 3.2 Gen 1 (1 front, 2 rear) (one of them with PowerShare)
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data Link Protocols
Bluetooth, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet Controllers
Intel I219-LM
Features
Dual stream (2x2)
Host Interface
M.2 2230
Wireless LAN
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Chipset Type
Intel Q670
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Ultra Small Form Factor
Form Factor (RAM)
SO-DIMM 262-pin
Input Device Type
Keyboard (on selected markets only), Mouse (on selected markets only)
Interface
USB
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Mouse Name
Dell MS116 USB Optical Mouse
Operating Humidity
20 - 80% (non-condensing)
Technology
Optical
Printer Product Type
None
Keyboard Name
Dell KB216 Multimedia Keyboard
Manufacturer Form Factor
Micro
Packaged Quantity
1
Product Type
Personal computer
Security Slot Type
Kensington security slot
Theft Protection
Chassis intrusion switch, Padlock loop, Security lock slot (cable lock sold separately)
Slots
1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module), 2 M.2 Card - 2230/2280 (for SSD)
Bundled Services
3 Years Basic Onsite Service after Remote Diagnosis with Hardware-Only Support
Operating System
Windows 11 Pro
Operating System Edition
Windows 11 Pro
Operating System Language
English / Spanish / French / Brazilian Portuguese
Operating System Platform
Windows
Software Type
Activate your Microsoft 365 for a 30 day trial, Dell Additional Softwares, Intel Connectivity Performance Suite, Intel Rapid Storage Technology
Frequency
50/60 hertz
Power Device Type
Power adapter
Power Provided
90 watt
Required Voltage
AC 100-240 volt
Color Category
Black
Height
7.2 inch
Weight
2.73 lbs
Width
1.4 inch
Depth
7 inch
ENERGY STAR Certified
Yes
EPEAT Compliant
Yes
EPEAT Level
EPEAT Gold
TCO Certified
No
