Tech specs
Brand
Elo
Product Line
Elo
Model
5554L
Edition
Commercial Grade
Manufacturer
Elo TouchSystems
Interfaces
2 x HDMI, 4 x Micro-USB, DisplayPort 1.4, Headphones (mini-jack), LAN (RJ-45), OSD control (RJ-45), RS-232 (mini-jack), USB (Type A), USB-C
Display Image Brightness
500 candela per square metre
Color Support
1.07 billion colors
Display Contrast Ratio
1100:1
Display Screen Technology
TFT active matrix
Display Type
LED-backlit LCD monitor
Features
24/7 operating mode, Ambient light sensor, Anti-friction glass, Anti-glare, Projected Capacitive Touch (P-CAP) technology
Form Factor
Open frame
Horizontal Refresh Rate
30 - 135 kHz
Horizontal Viewing Angle
+89 / -89
Image Brightness with Touchscreen
430 candela per square metre
Input Signal
2xHDMI, DisplayPort, USB-C
Interface
DisplayPort, HDMI, USB-C
Native Resolution
3840 x 2160
Response Time
8 millisecond
Screen Size
54.6 inch
Screen Size (metric)
138.7 centimetre
Touchscreen
Yes
Typical Response Time
8 ms (typical)
Vertical Refresh Rate
24 - 64 Hz
Vertical Viewing Angle
+89 / -89
Video Format
4K
V-Sync Rate at Max Res.
60 hertz
Monitor Aspect Ratio
16:9
Display Backlight Technology
LED backlight
Output Type
Speaker(s)
Speaker Output Power
10 watt
Speakers Configuration
Stereo
Frequency
50/60 hertz
Power Consumption (Off Mode)
0.38 watt
Power Consumption (Typical)
111.87 watt
Required Voltage
AC 100-240 volt
Sleep-Mode Power Consumption
1.52 watt
Built-in Devices
USB 2.0 hub
Input Device Type
Touchscreen
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Movement Detection Technology
Projected capacitive
MTBF
50,000 Hours
Operating Humidity
20 - 80%
Built-in USB Hub
Yes
Flat Panel Mount Interface
400 x 400 mm, 600 x 600 mm, VESA
Packaged Quantity
1
TV Tuner Presence
No
Cables
1 x USB-C cable - 3.3 ft
Monitor Accessories Included
4 x M6 screw
Height
29.2 inch
Weight
66.29 lbs
Width
50.1 inch
Depth
2.4 inch
Color
Black
Color Category
Black
Compliant Standards
CB, CCC, CEL, China RoHS, cUL, FCC, IC, IK07, Mexico NOM, RCM, UL 60950, UL 62368-1, VCCI
ENERGY STAR Certified
Yes
Energy Star Version
8.0
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advanced replacement - 3 years
Limited Warranty
3 Year
