Tech specs
Form Factor
Integrated
Output Power Channel
16 Watt
Sound Output Mode
Mono
Type
Speaker(s)
Speaker Type
Mixed channel
Speakers Qty
1
Chassis Built-in Devices
Speaker
Connectivity Details Type
VGA cable
Included Qty
1
Type
None
Depth
11.7 in
Height
6.2 in
Weight
8.6 lbs
Width
13.6 in
Display Resolution Abbreviation
WXGA
Projector Image Brightness
3000 lumens
Type
LCD projector
Image Contrast Ratio
3000:1
Max Resolution
1280 x 800
Max Operating Temperature
95 °F
Min Operating Temperature
41 °F
Sound Emission
37 dB
Sound Emission (Economic Mode)
29 dB
Brand
Epson
Compatibility
PC
Manufacturer
Epson Stylus Pro
Model
435W
Packaged Quantity
1
Product Line
Epson PowerLite
Form Factor
External
Connector Qty
X 2
Connector Type
15 pin HD D-Sub (HD-15), 4 pin mini-DIN, 4 pin USB Type A, 4 pin USB Type B, 9 pin D-Sub (DB-9), Mini-phone stereo 3.5 mm, RCA, RJ-45
Interface (Output)
Audio line-in, Audio line-out, Component video / RGB input, Composite video input, Hi-Speed USB, Microphone, Network, Serial RS-232C, S-video input, USB, VGA output
Purpose Location
Management
Qty
1, 2
Included Accessories
Wireless remote control
Security Features
Password protection, Security bar, Security lock slot (cable lock sold separately)
LAN and Wireless Image Transferring Protocols
Wired LAN
LAN and Wireless Presentation
LAN
Form Factor
Internal
Frequency Required
50/60 Hz
Nominal Voltage
AC 120/230 V
Type
Power supply
Brightness
3000 lumens
Brightness (Color)
3000 lumens
Class
Digital projector
Color Support
16.7 million colors
Contrast Ratio
3000:1
Digital Zoom Factor
1.35x
Display Format
1,024,000 pixels (1,280 x 800) x 3
Display Resolution Abbreviation
WXGA
High Definition
High Definition
Max Image Size
116 in
Max Screen Distance
4 ft
Min Image Size
53.1 in
Min Screen Distance
1.8 ft
Native Aspect Ratio
Widescreen
Native Resolution
1280 x 800
Portability
Non-portable
Projector Features
EPSON 3LCD technology, Short Throw Technology
Recommended Use
Presentation and multimedia
Throw Ratio
0.48 - 0.65:1
Type
LCD projector
Lamp Capacity
230 Watt
Lamp Life Cycle
4000 hour(s)
Lamp Life Cycle (Economic Mode)
6000 hour(s)
Lamp Type
E-TORL UHE
Focus Type
Manual
Horizontal Keystone Correction
-15 / +15
Keystone Correction Direction
Horizontal, Vertical
Lens
Short-throw fixed lens
Lens Aperture
F/1.8
Vertical Keystone Correction
-15 / +15
Zoom Type
Manual
Support Details Full Contract Period
2 years, 90 days
Support Details Type
Limited warranty
Type
2 years warranty
Component
Lamp
Type
None
Analog Video Format
NTSC, NTSC 4.43, PAL, PAL 60, PAL-M, PAL-N, SECAM
Analog Video Signal
Component video, Composite video, RGB, S-Video
Digital Video Standard
High-Definition Multimedia Interface (HDMI)
Video Interfaces
Composite video, S-Video, VGA
Analog Video Signal
RGB
