Tech specs
Brand
Extreme Networks
Product Line
Extreme Networks ExtremeSwitching Industrial Ethernet Switches
Model
ISW 8-10/100P, 4-SFP
Manufacturer
EXTREME NETWORKS
Flash Memory Installed
16 megabyte
RAM Installed
128 megabyte
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Features
4MB packet buffer, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Back Pressure Support, Broadcast Storm Control, DHCP client, DHCP relay, DHCP server, DHCP snooping, Flow control, Full duplex mode, Half duplex mode, IGMP snooping, Link Aggregation Control Protocol (LACP), MAC and IP-based ACLs support, Management Information Base (MIB) II, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, Port Security, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, SNTP support, Spanning Tree Protocol (STP) support, Store and forward, Storm Control, Syslog support, Tagged VLAN, VLAN support
Form Factor (Hubs & Switches)
DIN rail mountable, Wall-mountable
Jumbo Frame Support
9KB
MAC Address Table Size
8K entries
Manageable
Yes
PoE Budget
240 watt
Ports
8
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Routing Protocol
IGMP, IGMPv2, IGMPv3
Status Indicators
Port status, Power, Status
Subcategory
Network hubs and switches
Switching Type
Fast Ethernet
Interface Provided
4 x 1000Base-X SFP, 8 x 100Base-TX RJ-45 PoE+
Port Quantity
8
Port Type
10/100 (PoE+)
Ports Type (2nd)
Gigabit SFP
Power Consumption Operational
15 watt
Redundant Power Supply
Yes
Max Operating Temperature
167 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
>25 Years
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS, TACACS+
Capacity
Queues per port: 8, VLANs supported: 1024
Device Type
Internal power supply
Packaged Quantity
1
Performance
Aggregate bandwidth: 9.6 Gbps, Forwarding performance: 7.14 Mpps
Ports (2nd) Quantity
4
Height
6.1 inch
Weight
3.11 lbs
Width
3 inch
Depth
5 inch
Color Category
Black, Purple
Compliant Standards
CB, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1-03, EMC 2004/108/EC, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-2, EN 61000-6-4, FCC Part 15 A, ICES-003 Class A, IEC 60950-1 Second Edition, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IP30, RoHS, UL 60950-1 Second Edition, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
