Tech specs
Brand
Extreme Networks
Product Line
Extreme Networks ExtremeWireless
Model
AP305C
Manufacturer
EXTREME NETWORKS
Compliant Standards
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.4, IEEE 802.3af, IEEE 802.3at
Connectivity Technology
Wireless
Data Link Protocols
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
2x2:2 MU-MIMO technology, Direct Sequence Spread Spectrum (DSSS), Dual band, Orthogonal Frequency Division Multiplexing (OFDM), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Security slot (Kensington security lock compatible), WPA encryption
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE
Product Type
Wireless access point
Spread Spectrum Method
DSSS, OFDM
Wireless LAN
802.11a/b/g/n/ac Wave 2/ax, Bluetooth 5.0
Interface Provided
1 x 1000Base-T (PoE) - RJ-45, 1 x USB 2.0 - Type A
Power Consumption Operational
16.28 watt
Antenna Form Factor
Internal
Encryption
WPA3
Line Coding Format
1024 QAM, 256 QAM
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 95% (non-condensing)
Country
EMEA, Rest of World
IoT Communications Technology
Bluetooth Low Energy (LE), Zigbee
Packaged Quantity
1
Ruggedized Design
Indoor
Service Activation
No
Height
1.5 inch
Weight
13.4 ounce
Width
5.2 inch
Depth
5.2 inch
Color Category
White
Compliant Standards
AN/NZS 60950.1, AS/NZS 4268, CISPR 32, EN 300 328 V2.1.1, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 489-3 V2.1.1, EN 301 893 V2.1.1, EN 50385, EN 50581:2012, EN 55011:2009+A1:2010, EN 55024:2010+A1:2015, EN 55032:2015 Class B, EN 60601-1-2, EN 60601-1-2:2015, EN 60950-1, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 62311:2008, EN 62368, EN 62479:2010, FCC CFR47 Part 15 B Class B, FCC Subpart C 15.247, FCC Subpart E 15.407, ICES-003 Class B, IEC 60601-1-2, IEC 60950-1, IEC 62368, Intertek, RoHS 2011/65/EU, RSS-247
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
