Tech specs
Brand
Fortinet
Product Line
Fortinet FortiAP
Model
U431F
Manufacturer
Fortinet
Compliant Standards
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11j, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
Connectivity Technology
Wired, Wireless
Data Link Protocols
2.5 Gigabit Ethernet, Bluetooth, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, RS-232
Data Transfer Rate
4.804 GBps
Features
4x4 MIMO technology, 802.1x authentication, Black list, Bluetooth Low Energy Beaconing, Bridge mode, Captive Portal, iBeacon technology, LED off mode, Low Density Parity Check (LDPC), MAC address filtering, Maximum Likelihood Demodulation (MLD), Maximum Ratio Combining (MRC), Mesh networking, MIMO Power Save, MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Packet Sniffer Mode, Pre-Shared Key (PSK), Security lock slot (cable lock sold separately), Short Guard Interval, Spectrum analyzer, Transmit Beam-forming (TxBF) ready, Tunneling, White list, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS)
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE+
Product Type
Wireless access point
Wireless LAN
802.11a/b/g/n/ac Wave 2/ax, Bluetooth
Interface Provided
1 x 1000Base-T (PoE+) - RJ-45, 1 x 2500Base-T - RJ-45, 1 x RS-232 - RJ-45, 1 x USB - Type A
Power Consumption Operational
24.5 watt
Antenna Form Factor
Internal
Antenna Gain Level
5 DBi
Antennas
10
Encryption
EAP-AKA, EAP-FAST, EAP-SIM, PEAP, TLS, TTLS, WEP, WPA, WPA2, WPA3
Line Coding Format
1024 QAM, 64 QAM, OFDMA
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
30 Year
Operating Humidity
10 - 90% (non-condensing)
Authentication Method
EAP-AKA, EAP-FAST, EAP-GTC, EAP-SIM, Extensible Authentication Protocol (EAP), MS-CHAP v.2, Radio Service Set ID (SSID)
Capacity
Maximum number of configured SSIDs: 16, Wireless clients per Wi-Fi radio: up to 512
Country
Americas
Packaged Quantity
1
Ruggedized Design
Indoor
Service Activation
No
Included Accessories
Ceiling mounting kit, T-Rail mounting kit, Wall mounting kit
Height
2.3 inch
Weight
15.98 ounce
Width
8.5 inch
Depth
8.5 inch
Color Category
Black, White
Compliant Standards
FCC, LVD, RoHS
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
