Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
1101E
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC CP9/NP6
Hard Drive Capacity
480 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
2
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Anti-malware protection, Antivirus analysis, CAPWAP support, Content filtering, Firewall protection, Intrusion Prevention System (IPS), Traffic shaping, VPN support, Web threat protection, Zero-touch provisioning (ZTP)
Form Factor
Rack-mountable
Network Standard
IPSec, IPv4, IPv6, SCTP, TCP/IP, UDP/IP
Product Type
Security appliance
Remote Management
HTTP
Status Indicators
Alarm, HA, Power, Status
Interface Provided
1 x console - RJ-45, 16 x 1000Base-T - RJ-45, 2 x 1000Base-T (management) - RJ-45, 2 x 40Gb Ethernet - QSFP+, 2 x USB 3.0 - Type A, 4 x 10Gb Ethernet - SFP+, 4 x 10Gb Ethernet/25Gb Ethernet - SFP+/SFP28, 8 x 1000Base-X - SFP (mini-GBIC)
Bundled Services
5 years FortiCare 24X7 Service + 5 years FortiGuard
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
222 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Operating System Edition
FortiOS
Encryption
256-bit AES, 256-bit SHA, SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 100000, Concurrent sessions: 8000000, Concurrent SSL VPN users: 10000, Firewall policies: 100000, Gateway to gateway IPSec VPN Tunnels: 20000, New sessions per second: 500000, Number of FortiAP devices: 4096, Number of FortiSwitches: 128, Number of FortiToken devices: 20000, Number of registered FortiClients: 20000, SSL inspection concurrent sessions: 780000, Virtual domains: 10 (maximum 250)
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Application control (AVC) throughput: 26 Gbps, CAPWAP throughput (1444 byte, UDP): 43 Gbps, Firewall latency (64-byte UDP): 3 µs, Firewall throughput (1518-byte packet size): 80 Gbps, Firewall throughput (512-byte packet size): 80 Gbps, Firewall throughput (64-byte packet size): 45 Gbps, Firewall throughput: 67.5 Mpps, IPS throughput (enterprise traffic mix): 12.5 Gbps, IPv6 firewall throughput (86-byte packet size): 45 Gbps, NGFW throughput: 9.8 Gbps, SSL inspection throughput: 10 Gbps, SSL inspection throughput: 6500 connections per second, Threat protection throughput: 7.1 Gbps, VPN throughput (512-bit IPSec): 48 Gbps, VPN throughput (SSL): 8.4 Gbps
Included Accessories
2 SX SFP transceivers
Height
3.5 inch
Height (Rack Units)
2
Weight
25.46 lbs
Width
17.4 inch
Depth
17.6 inch
Color Category
Silver
Compliant Standards
CB, C-Tick, cUL, FCC Part 15 A, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, IPv6 Ready, UL, USGv6, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
