Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
200E
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC CP9/NP6Lite
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Anti-virus protection, Content filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), Manageable, VPN support
Form Factor
Rack-mountable
Product Type
Security appliance
Status Indicators
Alarm, HA, Power, Status
Interface Provided
1 x console - RJ-45, 1 x USB 2.0 - Type A, 14 x 1000Base-T - RJ-45, 2 x 1000Base-T - RJ-45 (WAN), 2 x 1000Base-T (management) - RJ-45, 4 x 1000Base-X - SFP (mini-GBIC)
Frequency
50/60 hertz
Power Consumption Operational
109.9 watt
Redundant Power Supply
Optional
Encryption
SSL
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 5000, Concurrent SSL VPN users: 300, Concurrent TCP sessions: 2000000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, New sessions per second: 135000, Number of FortiAP devices: 128, Number of FortiClient devices: 600, Number of FortiToken devices: 1000, Virtual domains: 10
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Application control (AVC) throughput: 3.5 Gbps, CAPWAP throughput: 1.5 Gbps, Firewall latency (64-byte UDP): 3 µs, Firewall throughput (1518-byte UDP): 20 Gbps, Firewall throughput (512-byte UDP): 20 Gbps, Firewall throughput (64-byte UDP): 9 Gbps, Firewall throughput: 13.5 Mpps, IPS throughput (HTTP): 6 Gbps, IPS throughput: 2.2 Gbps, NGFW throughput: 1.8 Gbps, SSL inspection throughput: 1 Gbps, Threat prevention throughput: 1.2 Gbps, VPN throughput (512-bit IPSec): 9 Gbps, VPN throughput (SSL): 900 Mbps
Height (Rack Units)
1
Weight
11.9 lbs
Compliant Standards
BSMI, CB, cUL, FCC Part 15 B Class A, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, RCM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
