Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
80F
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC SOC4
Processors Installed
1
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
3G/4G USB Dongle Support, Fanless, VPN support
Form Factor
Desktop
Network Standard
IPSec
Product Type
Security appliance
Interface Provided
1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN), 8 x 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
15.4 watt
Power Supplies Installed
2
Operating System Edition
FortiOS
Encryption
SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 2500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 1500000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, New TCP sessions per second: 45000, Number of FortiAP devices (tunnel mode): 16, Number of FortiAP devices: 32, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 100000, SSL inspection CPS: 700, Virtual domains: 10
Device Type
External power adapter
Packaged Quantity
1
Service Activation
No
Network Device
Application control throughput: 1.8 Gbps, CAPWAP throughput: 9 Gbps, Firewall latency (64-byte UDP): 4 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 7 Gbps, Firewall throughput: 10.5 Mpps, IPS throughput: 1.4 Gbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 715 Mbps, Threat protection throughput: 900 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 950 Mbps
Height
1.5 inch
Weight
5.29 lbs
Width
8.5 inch
Depth
6.3 inch
Color Category
White
Compliant Standards
BSMI, CB, cUL, FCC, ICES, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, RCM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Compare to similar models
- Availability
- Rating
- Connectivity Technology
- Data Link Protocols
- Form Factor
- Ports
- Product Type
- Data Transfer Rate
-
In Stock
-
Not Yet Rated
- Wired
- Fast Ethernet,Ethernet,Gigabit Ethernet
- Desktop
- —
- Security appliance
- —
-
4-6+ Weeks
-
Not Yet Rated
- Wired,Wireless
- Fast Ethernet,Ethernet,Gigabit Ethernet
- Desktop
- 10
- Security appliance
- —
-
In Stock
-
Not Yet Rated
- Wired
- 5 Gigabit Ethernet,10 Gigabit Ethernet,Gigabit Ethernet,2.5 Gigabit Ethernet
- Desktop
- —
- Security appliance
- —
-
In Stock
-
Not Yet Rated
- Wired
- Gigabit Ethernet
- Desktop
- —
- Security appliance
- —
Accessories
- CDW Recommends (5) total accessories
- Security (1) total accessories
View More Accessories
Warranties
Services
1-8 of 311 reviews
Easy interface and resilience against power interruptions improve network security
What is our primary use case?
We are using Fortinet FortiGate firewall as a data center firewall.
What is most valuable?
Two aspects I'm happy with regarding Fortinet FortiGate firewall are the easy user interface and its resilience during power interruptions. We experienced two power interruptions where the
Read more
Security features significantly improve data protection and instill client confidence
What is our primary use case?
We are a systems integrator in Paraguay, and my task is usually to configure Fortinet FortiGate as a perimeter firewall and provide all the security features to our clients.
What is most valuable?
Some of the best features of Fortinet FortiGate include the next-generation firewa
Read more
Hardware is very stable but technical support needs improvement
What is our primary use case?
Our main use case for Fortinet FortiGate is as a firewall. We are using it for cybersecurity purposes.
How has it helped my organization?
Our main purpose when we started working with Fortinet FortiGate was to secure our network in all aspects. Fortinet FortiGate performs a very
Read more
User interface offers improved control and smoother connections across branches
What is our primary use case?
The main use cases for Fortinet FortiGate are mostly for an industrial company firewall, focusing on firewall, web server, and new-gen, next-gen firewall.
What is most valuable?
What I appreciate about Fortinet FortiGate is that the UI is easier than what I've previously known f
Read more
Can secure some sites and good ROI but challenges with web filter integration
What is our primary use case?
I'm using it for web filter and then using it for VPN connection user to site, and I'm using it to make a virtual ID to link a real ID from the server to provider to my servers to publish servers.
What is most valuable?
I work with Fortinet FortiGate SD WAN. I configure the SD W
Read more
Comprehensive and easy to manage with a simple GUI
What is our primary use case?
Most of our clients are SMB. We have several support contracts, and as a way to standardize all the products and processes, we ask our clients to switch to Fortinet FortiGate as a firewall, and that's how we standardize our process. Most of our clients we support with a support co
Read more
Enables customers to manage security effortlessly with intuitive features and easy integration
What is our primary use case?
My customers use Fortinet FortiGate for their branches and campuses; we have provided it for small retail and industrial networks.
Chennai is totally based on MND and BFSI for the factories, and since Fortinet FortiGate provides OT Security, they have numerous features. In the sa
Read more
A robust and customizable firewall with constant updates
What is our primary use case?
We use Fortinet FortiGate for gateway security, specifically for VPN access, security control, and filtering of traffic. For net monitoring, it has the capability to put the network traffic over to the analyzer. We use FortiAnalyzer to look at the traffic and to see what's happeni
Read more
