Tech specs
Brand
Fortinet
Product Line
Fortinet FortiSwitch Rugged
Model
424F-POE
Manufacturer
Fortinet
Flash Memory Installed
256 megabyte
RAM Installed
1 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 1588v2, IEEE 1613, IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
802.1x authentication, Access Control List (ACL) support, Auto-discovery, Automatic topology detection, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), DHCP relay, DHCP server, DHCP snooping, DSCP based ToS, Dynamic ARP Inspection (DAI), Encapsulated Remote SPAN (ERSPAN), Fanless, Firewall protection, FTP support, High Availability, High-speed Self Recovery (HSR), IGMP proxy, IGMP querier, IGMP snooping, IP source guard, IPFIX, IP-MAC binding, Link Aggregation Group (LAG), LLDP support, LLDP-MED, Loop Guard, MAC black/whitelist, Media Redundancy Protocol (MRP), MLD proxy, MLD querier, MLD snooping, Multichassis link aggregation (MC-LAG), NetFlow, Network Access Control (NAC), Parallel Redundancy Protocol (PRP), Policy based access control, Policy based routing, Port mirroring, Private VLAN, RA guard, Rapid PVST (RPVST), Remote Switch Port Analyzer (RSPAN), sFlow, SNTP support, Storm Control, STP BPDU Guard, STP Root Guard, Switched Port Analyzer (SPAN), Time Domain Reflectometry (TDR), Unified threat management (UTM), VLAN / port mapping, VLAN support, Wake On LAN (WOL), Zero-Touch Deployment
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
Yes
MAC Address Table Size
32K entries
Manageable
Yes
PoE Budget
421 watt
Ports
24
Power Over Ethernet (PoE)
UPOE
Product Type
Switch
Remote Management
CLI, DHCP, HTTP, HTTPS, IPv4, IPv6, MIB, RMON 1, SNMP 1, SNMP 2c, SNMP 3, SSH, Syslog, TCP/IP, Telnet, TFTP, UDP
Routing Protocol
BGP, BGP-4, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IS-IS, MLD, MSTP, OSPF, OSPFv2, PIM-SM, PIM-SSM, RIP-2, RSTP, Static IP routing, STP, URPF, VRRP
Status Indicators
Alarm, Link/activity, Management, PoE max, Power
Subcategory
Network hubs and switches
Switching Type
2.5 Gigabit Ethernet
QSFP Slots
10 Gigabit SFP+
Interface Provided
1 x antenna input SMA, 1 x management (Gigabit LAN) RJ-45, 1 x serial (console) RJ-45, 1 x USB 2.0 Type A, 12 x 1/2.5GBase-T RJ-45 UPOE - 60 W, 12 x 1/2.5GBase-X SFP+, 2 x 40GBase-X QSFP+, 4 x 10GBase-X SFP+
Port Quantity
12
Port Type
2.5GBase-T (UPOE)
Ports Type (2nd)
1/2.5 Gigabit SFP+
Features
Power Polarity Reverse Protect
Redundant Power Supply
Yes
Max Operating Temperature
158 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
>30 Year
Operating Humidity
5 - 95% RH (non-condensing)
Authentication Method
RADIUS
Capacity
ACL: 1500, Link aggregation groups: up to 24, Packet buffer size: 4 MB, Queues per port: 8, Spanning Tree Protocol instances: 16, VLANs supported: 4000
Packaged Quantity
1
Performance
Latency: < 1 µs, Packets per second: 584 Mpps, Switching capacity: 360 Gbps
Ports (2nd) Quantity
12
Ports (3rd) Quantity
4
Ports (4th) Quantity
2
Ports (4th) Type
40 Gigabit QSFP+
Cables
1 x USB to RJ-45 console cable
Included Accessories
2 rack mount brackets, 4 rubber feet, 6-pin terminal block
Height
1.7 inch
Weight
13.87 lbs
Width
17.3 inch
Depth
16.1 inch
Color Category
Gray
Compliant Standards
AS/NZS CISPR 32 Class A, BSMI, CISPR 32, CNS 15598-1:2020, CNS 15936: 2016 Class A, Directive 2014/30/EU, EMC, EN 55032:2015 Class A, EN 55032:2015:2020 Class A, EN 55035:2017/A11:2020, FCC, FCC Part 15 B Class A, ICES, ICES-003 Issue 7: 2020 Class A, IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61850-3, IEC 62368-1 Second Edition, IEC 62368-1 Third Edition, IP40, LVD 2014/35/EU, RCM, RoHS, UL 62368-1 Third Edition, VCCI, VCCI-CISPR 32:2016 Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
