Tech specs
Brand
Honeywell
Product Line
Honeywell Genesis XP
Model
7680g
Manufacturer
Honeywell
Connectivity Technology
Wired
Barcode Symbology Supported
Australian Post, Aztec code, China Post, Chinese Sensible Code, Codabar, Codablock A, Codablock F, Code 11, Code 128, Code 39, Code 93, Data Matrix, DotCode, EAN/JAN-13, EAN/JAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1-128, GS1-128 Composites, Han Xin, Hong Kong 2 of 5, IATA 2 of 5, Interleaved 2 of 5, ISBN, ISBT 128, Korea Post, MacroPDF417, Matrix 2 of 5, MaxiCode, MicroPDF417, MSI, NEC 2 of 5, PDF417, PLANET, Postnet, QR code, Straight 2 of 5, Telepen, TLC39, Trioptic Code, UPC-A, UPC-A/EAN-13 with Extended Coupon Code, UPC-E0, UPC-E1
Scan Mode
Fixed projection
Sensor Resolution
1280 x 800
Electric Current Required
400 mA
Power Consumption Operational
2 watt
Drop Specification
5 ft
Form Factor
Desktop
Image Sensor Type
2D imager
Interface
Interface cable required
Max Operating Temperature
122 degree Fahrenheit
Max Scan Field
9.84 inch
Min Operating Temperature
32 degree Fahrenheit
Minimum Bar Width
3 milli-inch
Operating Humidity
0 - 95% (non-condensing)
Print Contrast Signal (PCS)
20%
Skew (Degrees)
65
Barcode Type
Stationary
Country
Canada, Latin America, United States
Scanner Functionality
Barcode scanner
Features
Digimarc Barcode Technology, Rugged
Max Coverage Angle
65
OK Notification
Beeper, LED indicator
Packaged Quantity
1
TTL Decoding
Decoded
Included Accessories
Stand
Height
4.1 inch
Weight
11.99 ounce
Width
3.1 inch
Depth
1.6 inch
Color
Black
Color Category
Black
Compliant Standards
IP52
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
