Tech specs
Manufacturer
Hewlett Packard Non Smart Buy
Brand
HP
Product Line
HP EliteDesk
Model
800 G5
Localization
English
Country Kits
United States
Packaged Quantity
1
Type
Personal computer
Platform Technology
Intel vPro Technology
Hard Drive Capacity
128 GB
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Small form factor
Manufacturer Form Factor
Small form factor
Built-in Devices
Speaker
Type
Pentium Gold
Number of Cores
Dual-Core
Processor Number
G5420
Installed Qty
1
Max Supported Qty
1
Upgradability
Upgradable
Manufacturer
Intel
Clock Speed
3.8 GHZ
Processor Main Features
Intel Smart Cache
Processor Socket
LGA1151 Socket
Chipset Type
Intel Q370
Installed Size
4 megabyte
Form Factor
DIMM 288-pin
Technology
DDR4 SDRAM
Installed Size
8 GB
Max Supported Size
128 GB
Configuration Features
1 x 8 GB
Data Integrity Check
Non-ECC
Slots Qty
4
Empty Slots
3
Memory Speed
2666 megahertz
Rated Memory Speed
2666 megahertz
Features
Unbuffered
Type
Serial ATA
Interface Type
Serial ATA-600
Channel Qty
3
Installed Qty
1
Type
SSD
SSD Form Factor
M.2 2280
Interface Class
PCI Express
Installed Qty
1
Capacity
128 GB
Hard Drive Features
NVM Express (NVMe), Triple-level cell (TLC)
Type
None
Type
None
Type
None
Drive Type
No optical drive
Type
None
Drive Type
No optical drive
Type
None
Type
None
Type
None.
Graphics Processor
Intel UHD Graphics 610
Graphics Processor Series
Intel UHD Graphics
Video Interfaces
DisplayPort
HDCP Compatible
Yes
Memory Allocation Technology
Dynamic Video Memory Technology
Sound Output Mode
Stereo
Max Sampling Rate
192 kilohertz
Compliant Standards
High Definition Audio
Type
None
Type
Keyboard, Mouse
Keyboard Name
HP Business Slim Keyboard
Interface
USB
Keyboard Localization
US
Keyboard Layout
QWERTY
Technology
Optical
Interface
USB
Ethernet Controller(s)
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
ACPI support, PXE 2.1 support, Wake on LAN (WoL)
Compliant Standards
IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Bays
1 (total) / 0 (free) x external 5.25" Slim Line, 1 (total) / 1 (free) x internal 2.5", 2 (total) / 2 (free) x internal 3.5"
Slots
1 (total) / 1 (free) x M.2 Card - 2230 (x1 mode), 1 (total) / 1 (free) x PCIe 3.0 x16, 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode), 2 (total) / 1 (free) x M.2 Card - 2230/2280 (x4 mode), 2 (total) / 2 (free) x PCIe 3.0 x1
Interfaces
1 x audio line-in, 1 x audio line-out, 1 x headphones (1 in front), 1 x headphones/microphone (1 in front), 1 x LAN (Gigabit Ethernet), 1 x USB-C 3.1 Gen 2 (1 in front) (charging), 2 x DisplayPort, 2 x USB 3.1 Gen 1, 4 x USB 2.0 (2 front, 2 rear) (two of them with wake functionality, one of them is fast-charging), 4 x USB 3.1 Gen 2 (2 front, 2 rear)
Family
DOS
Type
FreeDOS
Language
English
Type
Power supply
Power Provided
250 watt
Nominal Voltage
AC 120/230 V
Frequency Required
50/60 hertz
Power Factor Correction
Yes (active)
Efficiency
92%
80 PLUS Certification
80 PLUS Platinum
Color Category
Black, Silver
Compliant Standards
ACPI, CCC, CECP, Common Criteria EAL4+, Low halogen, RoHS, SEPA, WEEE
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
ENERGY STAR Certified
Yes
Width
12.1 inch
Depth
13.3 inch
Height
3.9 inch
Weight
13.51 lbs
Shipping Width
15.7 inch
Shipping Depth
19.6 inch
Shipping Height
9.1 inch
Shipping Weight
19.84 lbs
Type
3-year warranty
On-Site Warranty
On-site
Service & Support
Limited warranty - parts and labor - 3 years - on-site
Min Operating Temperature
41 degree Fahrenheit
Max Operating Temperature
95 degree Fahrenheit
Humidity Range Operating
5 - 90%
