Tech specs
Brand
Aruba
Product Line
HPE Aruba
Model
6405 V2
Manufacturer
Aruba
Clock Speed
1.8 GHZ
Processor Brand
ARM
Processors Installed
1
Flash Memory Installed
32 GB
Memory Technology
DDR4 SDRAM
RAM Installed
16 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Form Factor (Hubs & Switches)
Rack-mountable
MAC Address Table Size
32768 entries
Manageable
Yes
Power Over Ethernet (PoE)
4PPoE
Product Type
Switch
Stackable
Stackable
Subcategory
Network hubs and switches
Interface Provided
1 x console RJ-45, 1 x management RJ-45, 1 x USB Type A host, 1 x USB-C console
Frequency
50/60 hertz
Power Supplies Supported
4
Redundant Power Supply
Optional
Redundant Power Supply Supported
N+1 (with optional power supply), N+N (with optional power supply)
Humidity Range Storage
15 - 95% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
15 - 95% (non-condensing)
Supported Devices
7
Airflow Direction
Front to back airflow
Authentication Method
RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+
Capacity
IGMP groups: 8192, IPv4 host table capacity:, IPv4 routes (Multicast): 8192, IPv4 routes (Unicast):, IPv6 routes (Multicast): 8192, IPv6 routes (Unicast):, MLD groups: 8192, Switched virtual interfaces (SVIs): 2048
Device Type
Internal power supply (not installed)
Packaged Quantity
1
Performance
Latency (1 Gbps): 5.32 µs, Latency (10 Gbps): 1.48 µs, Latency (100 Gbps): 1.42 µs, Latency (25 Gbps): 2.78 µs, Latency (40 Gbps): 1.31 µs, Switching capacity: 14 Tbps, Throughput: 5.7 Bpps
Rack Mounting Kit
Included
Included Accessories
Cable management kit, Rack mounting kit (2 post)
Height
12.1 inch
Height (Rack Units)
7
Weight
64.59 lbs
Width
17.4 inch
Depth
17.7 inch
Color Category
Black, Silver
Compliant Standards
CISPR 22 Class A, CISPR 32:2012 Class A, CISPR 35, CSA 60950-1 Second Edition, EN 50581:2012, EN 55022 Class A, EN 55024:2010 + A1:2001 + A2:2003, EN 55032:2012 Class A, EN 55035, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 62368-1:2014, FCC CFR47 Part 15, FCC Class A certified, ICES-003 Class A, IEC 60825-1:2007, IEC 60950-1:2005 Second Edition, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-8, RoHS, UL 62368-1 Second Edition, VCCI Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
