Tech specs
Brand
HPE
Product Line
HPE ProLiant
Model
DL380 Gen11 Network Choice
Manufacturer
HPE Smart Buy Express
Clock Speed
2.8 GHZ
Cores
16-core
Max Turbo Speed
3.9 GHZ
Processor Brand
Intel
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Processor Number
6526Y
Processor Type
Xeon Gold
Processors Installed
1
Server Scalability
2-way
Total Processor Supported
2
Upgradability
Upgradable
Available Memory Slots
28
Cache Memory
L3 cache
Cache Memory Installed
37.5 megabyte
Configuration Features
4 x 32 GB
Features
HPE SmartMemory, Registered, Slots 17 - 32 are available in two-processor configuration only
Max Memory Supported
8 TB
Memory Slots
32
Memory Speed
5200 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
128 GB
Rated Memory Speed
5600 megahertz
Drive Type
No optical drive
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller (2nd)
None
Storage Controller Name
HPE NS204i-u
Type
None
Hard Drive Interface Type
No HDD
Compliant Standards
OCP 3.0
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controllers
Broadcom BCM5719
Ethernet Ports
4 x Gigabit Ethernet
Features
PXE support, Wake On LAN (WOL)
Host Interface
Open Compute Project mezzanine (OCP) 3.0
Remote Management
IPMI 2.0, SMASH CLP, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Expansion Bays
1 (total) / 1 (free) x external Universal Media Bay, 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height, 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode), 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode), 2 (total) / 2 (free) x FlexibleLOM
Interface Provided
1 x HPE iLO - RJ-45 (1 rear), 1 x USB 3.0 (1 in front) (HPE iLO Service Port), 1 x VGA (1 rear), 4 x LAN (Gigabit Ethernet), 4 x USB 3.0 (2 rear, 2 internal)
Display Technology
None.
Video Interfaces
VGA
Installed Size
16 megabyte
Power Device Type
Power supply - hot-plug
Power Provided
1000 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
80 PLUS Certification
80 PLUS Titanium
Operating System Edition
No operating system
OS Certified
Canonical Ubuntu, Citrix, Microsoft Windows Server, Oracle Linux, Red Hat Enterprise Linux, VMware ESXi
Software Type
HPE Server UEFI
Built-in Devices
LED panel
Chipset Type
Intel C741
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Rack-mountable
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
NVM Express
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% RH (non-condensing)
Controllers Included
1
Country
Canada, United States
Printer Product Type
None
Hot-Swap Bays
8
Manufacturer Form Factor
Rack-mountable
Packaged Quantity
1
Product Type
Server
Server Storage Bays
Hot-swap
Server Swappable Drive Form Factor
2.5"
Server Swappable Drive Form Factor (metric)
6.4 cm
Server Swappable Drive Interface
NVMe
Included Accessories
4 standard fans, 6 high performance fans, High-performance heatsink, HPE Easy Install Rail 3 Kit
Height
3.4 inch
Height (Rack Units)
2
Weight
35.27 lbs
Width
17.6 inch
Depth
28.6 inch
Color Category
Black, Silver
Compliant Standards
ACPI 6.3, Active Directory v1.0, AES, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-2, Redfish API, SMBIOS 3.2, TLS v1.2, Triple DES, WEEE 2002/95/EC
ENERGY STAR Certified
Yes
Energy Star Version
3.0
EPEAT Compliant
No
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Limited Warranty
3 Year
