Tech specs
Brand
HPE
Product Line
HPE ProLiant
Model
DL380 Gen11 Network Choice
Manufacturer
HPE Smart Buy Express
Bus Type
Open Compute Project mezzanine (OCP)
Clock Speed
2 GHZ
Cores
16-core
Max Turbo Speed
3.4 GHZ
Processor Brand
Intel
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Processor Number
4514Y
Processor Type
Xeon Silver
Processors Installed
1
Server Scalability
2-way
Total Processor Supported
2
Upgradability
Upgradable
Available Memory Slots
28
Cache Memory
L3 cache
Cache Memory Installed
30 megabyte
Configuration Features
4 x 32 GB
Features
HPE SmartMemory, Registered, Slots 17 - 32 are available in two-processor configuration only
Max Memory Supported
8 TB
Memory Slots
32
Memory Speed
4400 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
128 GB
Rated Memory Speed
5600 megahertz
Buffer Size
4 GB
Channel Quantity
8
Drive Type
No optical drive
Hard Drive Capacity
480 GB
Installed Quantity
2
Interface Class
Serial ATA
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
RAID Levels
RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller (2nd)
None
Storage Controller Name
HPE MR408i-o Gen11 SPDM
Storage Controller Type
RAID
Type
None
Hard Drive Interface Type
SSD
Compliant Standards
OCP 3.0
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controllers
Broadcom BCM5719
Ethernet Ports
4 x Gigabit Ethernet
Features
PXE support, Wake On LAN (WOL)
Host Interface
Open Compute Project mezzanine (OCP) 3.0
Remote Management
IPMI 2.0, SMASH CLP, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Expansion Bays
1 (total) / 1 (free) x external Universal Media Bay, 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height, 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode), 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode), 2 (total) / 2 (free) x FlexibleLOM
Interface Provided
1 x HPE iLO - RJ-45 (1 rear), 1 x USB 3.0 (1 in front) (HPE iLO Service Port), 1 x VGA (1 rear), 4 x LAN (Gigabit Ethernet) - RJ-45, 4 x USB 3.0 (2 rear, 2 internal)
Display Technology
None.
Video Interfaces
VGA
Installed Size
16 megabyte
Power Device Type
Power supply - hot-plug
Power Provided
1000 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
80 PLUS Certification
80 PLUS Titanium
Operating System Edition
No operating system
OS Certified
Canonical Ubuntu 20.04.5 LTS, Canonical Ubuntu 22.04 LTS, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Oracle Linux 9, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Micro 5.3, SUSE Linux Enterprise Server 15 SP4, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1, VMware ESXi 8.0 update 2
Software Type
HPE Server UEFI
Built-in Devices
LED panel
Chipset Type
Intel C741
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Rack-mountable
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% RH (non-condensing)
Controllers Included
1
Country
Canada, United States
Printer Product Type
None
Hot-Swap Bays
8
Manufacturer Form Factor
Rack-mountable
Packaged Quantity
1
Product Type
Server
Server Storage Bays
Hot-swap
Server Swappable Drive Form Factor
2.5"
Server Swappable Drive Form Factor (metric)
6.4 cm
Server Swappable Drive Interface
SATA/SAS/NVMe
Included Accessories
4 standard fans, HPE Easy Install Rail 3 Kit, HPE standard heatsink
Height
3.4 inch
Height (Rack Units)
2
Weight
35.27 lbs
Width
17.6 inch
Depth
28.6 inch
Color Category
Black, Silver
Compliant Standards
ACPI 6.3, Active Directory v1.0, AES, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-2, Redfish API, SMBIOS 3.2, TLS v1.2, Triple DES, WEEE 2002/95/EC
ENERGY STAR Certified
Yes
Energy Star Version
3.0
EPEAT Compliant
No
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Limited Warranty
3 Year
