Tech specs
Brand
HPE
Product Line
HPE ProLiant
Model
ML350 Gen11 Base
Manufacturer
Hewlett-Packard
Clock Speed
2 GHZ
Cores
12-core
Max Turbo Speed
3.9 GHZ
Processor Brand
Intel
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Processor Number
4410Y
Processor Socket
LGA4677 Socket-E
Processor Type
Xeon Silver
Processors Installed
1
Server Scalability
2-way
Total Processor Supported
2
Upgradability
Upgradable
Available Memory Slots
15
Cache Memory
L3 cache
Cache Memory Installed
30 megabyte
Configuration Features
1 x 32 GB
Data Integrity Check
Advanced ECC
Features
Dual rank, HPE SmartMemory, Online Spare Memory, Registered, Slots 17 - 32 are available in two-processor configuration only
Max Memory Supported
8 TB
Memory Slots
16
Memory Speed
4000 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
32 GB
Rated Memory Speed
4800 megahertz
Channel Quantity
14
Drive Type
No optical drive
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
RAID Levels
RAID 0, RAID 1, RAID 10, RAID 5
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller (2nd)
None
Storage Controller Name
Intel VROC SATA Software RAID
Storage Controller Type
Serial ATA
Type
None
Hard Drive Interface Type
No HDD
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controllers
Broadcom BCM5719
Ethernet Ports
4 x Gigabit Ethernet
Features
PXE support, Wake On LAN (WOL)
Host Interface
Open Compute Project mezzanine (OCP) 3.0
Remote Management
SMASH CLP, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Expansion Bays
4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
4 (total) / 4 (free) x PCIe 5.0 x16 (x8 mode)
Interface Provided
1 x HPE iLO - RJ-45, 1 x HPE iLO - Type A (1 in front), 1 x serial, 1 x USB 2.0 (1 bottom), 1 x VGA, 4 x LAN (Gigabit Ethernet), 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 top)
Display Technology
None.
Video Interfaces
VGA
Installed Size
16 megabyte
Power Device Type
Power supply - hot-plug
Power Provided
800 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
Required Voltage
AC 100-120/200-240 volt
80 PLUS Certification
80 PLUS Platinum
Operating System Edition
No operating system
Software Type
HPE iLO Standard with Intelligent Provisioning
Built-in Devices
LED panel
Chipset Type
Intel C741
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Tower
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
Serial ATA-600
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% RH (non-condensing)
Controllers Included
1
Country
Americas
Printer Product Type
None
Hot-Swap Bays
4
Manufacturer Form Factor
Tower
Packaged Quantity
1
Product Type
Server
Security Slot Type
Kensington security slot
Server Storage Bays
Hot-swap
Server Swappable Drive Form Factor
3.5"
Server Swappable Drive Form Factor (metric)
8.9 cm
Server Swappable Drive Interface
SATA/SAS
Theft Protection
Padlock eye, Security lock slot (cable lock sold separately)
Included Accessories
3 standard fans
Height
18.2 inch
Height (Rack Units)
4
Weight
60.45 lbs
Width
6.9 inch
Depth
28 inch
Color Category
Black
Compliant Standards
ACPI 6.1, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, FIPS 140-3
ENERGY STAR Certified
Yes
EPEAT Compliant
No
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Limited Warranty
3 Year
