Tech specs
Brand
Newline
Product Line
Newline
Model
STV-5524-PLUS
Series
STV+ Series
Manufacturer
Newline
Cores
ARM Cortex-A73 Quad-Core
Storage Capacity
16 GB
Bluetooth Version
Bluetooth 5.0
Connect & Share
IP Control
Connectivity
Bluetooth, LAN, Wi-Fi
LAN Protocol
Ethernet
Wi-Fi Protocol
802.11ac
Connector Type
3 x HDMI input - rear, Audio line-out - rear, Component video input - rear, LAN - rear, RS-232 input - rear, SPDIF output - rear, USB 2.0 - rear, USB 3.0 - rear
HDMI Ports
3
USB Ports
2
Video Interface
Component, HDMI
Anti-glare Coating
2% haze, Anti-glare
Aspect Ratio
16:9
Backlight Technology
LED backlight
Brightness
260 candela per square metre
Features
Newline Display Management
Operating Hour
24 Hours
Response Time
6.5 millisecond
Screen Resolution
3840 x 2160
Television Diagonal Class
55 inch
Television Modes
Fast Boot mode, Landscape mode
Touchscreen
No
Frame Rate & Enhancement Technology
60 Hz Refresh Rate
Tuners
No tuner
Features
Wake on WLAN, WOL (Wake on LAN)
Frequency
50/60 hertz
Power Consumption Operational
140 watt
Power Device Type
Power supply
Required Voltage
AC 110-240 volt
Max Operating Temperature
104 degree Fahrenheit
Max Power Consumption
140 watt
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 80% (non-condensing)
Remote Control Type
Remote control
Speaker System
2 speakers
Speakers
2 x main channel speaker - 10 Watt
Total Output Power
20 watt
Additional Features
1.07 billion colors (8-bit+FRC)
Batteries Required Quantity
2
Commercial Use
Yes
Display Format
4K UHD (2160p)
Dynamic Contrast Ratio
4000:1
Flat Panel Mount Interface
400 x 300 mm
Graphics Processing Unit
ARM Mali-G52 MC1
Pixel Pitch
0.105 millimetre
Platform
Android
Product Type
LED-backlit LCD flat panel display
RAM
4 GB
Remote Control Battery Form Factor
AAA type
Screen Size Class
140 centimetre
TV Tuner Presence
No
USB Port
Yes
Viewing Angle
178°
Batteries Included
2
Remote Control Battery Included
Yes
Height
27.9 inch
Weight
24.91 lbs
Width
48.4 inch
Depth
3.4 inch
Design
Ultra thin bezel
Color Category
Black
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
VESA Mount Compatible
Yes
Standby Power Consumption
0.5 watt
