Tech specs
Brand
Newline
Product Line
Newline
Model
TT-5524ZPRO
Series
Z Pro Series
Manufacturer
Newline
Cores
ARM Cortex-A73 Quad-Core + ARM Cortex-A53 Quad-Core
Storage Capacity
64 GB
Application Store
Google Play
Bluetooth Version
Bluetooth 5.2
Connectivity
Bluetooth, LAN, Wi-Fi
LAN Protocol
Ethernet
Wi-Fi Protocol
802.11ax
Connector Type
3 x HDMI input, 3 x USB 3.0, 4 x touch, Audio line-out, DisplayPort input, HDMI output, Intel SDM (Smart Display Module) slot, LAN input, LAN output, Microphone input, RS-232, S/PDIF output, Service, USB, USB-C (camera only), USB-C with 100W Power Delivery
HDMI Ports
3
PC Interface
DisplayPort, USB-C
USB Ports
5
Video Interface
HDMI
Anti-glare Coating
7H Hard, Anti-fingerprint, Anti-glare, Antimicrobial coating
Aspect Ratio
16:9
Backlight Technology
LED backlight
Brightness
400 candela per square metre
Combined With
Touchscreen (multi touch) / 8-microphone array
Contrast Ratio
4000:1
Features
Open Pluggable Standard (OPS) support
Operating Hour
24 Hours
Response Time
8 millisecond
Screen Resolution
3840 x 2160
Television Diagonal Class
55 inch
Touchpoints
20
Frame Rate & Enhancement Technology
60 Hz Refresh Rate
Tuners
No tuner
Features
WOL (Wake on LAN)
Power Device Type
Power supply
Required Voltage
AC 100-240 volt
Max Operating Temperature
104 degree Fahrenheit
Max Power Consumption
550 watt
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 80% RH (non-condensing)
Remote Control Type
Remote control
Speaker System
2 speakers
Speakers
2 x main channel speaker - 20 Watt
Total Output Power
20 watt
Additional Features
TouchPro Projected Capacitive Technology (PCAP)
Backlight Life
50,000 hour(s)
Commercial Use
Yes
Display Format
4K UHD (2160p)
Flat Panel Mount Interface
400 x 400 mm
Graphics Processing Unit
ARM Mali-G52
LED Backlight Technology
Direct LED
Platform
Android
Product Type
LED-backlit LCD flat panel display
RAM
8 GB
Screen Size Class
140 centimetre
Sensors
Proximity sensor
Stand
Optional
TV Tuner Presence
No
USB Port
Yes
Viewing Angle
178°
Height
31.4 inch
Weight
61.73 lbs
Width
50.4 inch
Depth
3.1 inch
Color Category
Black
Compliant Standards
Google EDLA
VESA Mount Compatible
Yes
Standby Power Consumption
0.5 watt
