Plugable USB 3.0 and USB-C Dual 4K Display Docking Station w/ DisplayPort and HDMI for Windows and Mac,Vertical
$184.99
$139.95
Mfg # UD-6950Z
CDW # 7114810
| UNSPSC 43211602
Quick tech specs
- This USB laptop dock provides dual HDMI or DisplayPort video outputs,wired Gigabit Ethernet,3.5mm combination audio jack.6xUSB 3.0 ports. Includes USB 3.0 and USB-C cables for flexibility
- Compatible w/Windows 11,10,8.x,7,ChromeOS 100+,macOS 10.14+
- Backed by Plugable's Seattle-based support team, 2 year limited parts and labor warranty
- Equipped with dual HDMI and DisplayPort ports for two 4K monitor supporting resolutions up to 3840x2160@60Hz
- For use with web and productivity software
Know your gear
Performance Featuring the latest DisplayLink DL-6950 chipset, the Plugable UD-6950Z docking station lets you connect two external monitors up to a 4K@60Hz resolution using DisplayPort or HDMI to your Windows laptop, or desktop via USB 3.0. Additionally, the UD-6950Z dock allows you to connect up to eight accessories to the six USB 3.0 ports, a Gigabit Etherent connection and audio input/output port all through a single USB cable. 4K@60Hz Notes :
To achieve 4K @ 60Hz each connected monitor must support 4K @ 60Hz on the DisplayPort 1.2 or HDMI 2.0 This docking station does not support host charging, we recommend using the systems separate power supply for optimal performance.
Compatibility Our docking station is compatible with most modern laptops and desktops running Windows 10, 8.1 and 7 and macOS 10.14+ and requires the DisplayLink graphics software to be installed.
Not supported on Linux.
Does not support HDCP copy protected content (Blu-Ray, Netflix, Amazon Prime video, etc.). DisplayPort MST daisy-chain connections or Dual-Link DVI conversions are not supported from the DisplayPort outputs.
Gigabit Ethernet port requires a Full-Duplex network connection from the connected network device (router, switch, etc.).
Minimum System Specifications Intel SkyLake i3, Intel Core i7 or AMD A10 CPU at 2.0 GHz or Higher Intel HD 4000, AMD Radeon HD 8650, Nvidia GeForce 7xxM or better 8GB RAM USB 3.0 Port
In the Box Plugable UD-6950Z USB 3.0 Dual 4K Display Vertical Docking Station, USB 3.0 Type-A to Type-C Cable, USB 3.1 Type-C to Type-C Cable, Power Adapter (US AC Wall Outlet Plug, 20V@2A), Quick Installation Guide.
To achieve 4K @ 60Hz each connected monitor must support 4K @ 60Hz on the DisplayPort 1.2 or HDMI 2.0 This docking station does not support host charging, we recommend using the systems separate power supply for optimal performance.
Compatibility Our docking station is compatible with most modern laptops and desktops running Windows 10, 8.1 and 7 and macOS 10.14+ and requires the DisplayLink graphics software to be installed.
Not supported on Linux.
Does not support HDCP copy protected content (Blu-Ray, Netflix, Amazon Prime video, etc.). DisplayPort MST daisy-chain connections or Dual-Link DVI conversions are not supported from the DisplayPort outputs.
Gigabit Ethernet port requires a Full-Duplex network connection from the connected network device (router, switch, etc.).
Minimum System Specifications Intel SkyLake i3, Intel Core i7 or AMD A10 CPU at 2.0 GHz or Higher Intel HD 4000, AMD Radeon HD 8650, Nvidia GeForce 7xxM or better 8GB RAM USB 3.0 Port
In the Box Plugable UD-6950Z USB 3.0 Dual 4K Display Vertical Docking Station, USB 3.0 Type-A to Type-C Cable, USB 3.1 Type-C to Type-C Cable, Power Adapter (US AC Wall Outlet Plug, 20V@2A), Quick Installation Guide.
