Tech specs
Brand
Raritan
Product Line
Raritan PX intelligent
Model
PX3-5520R
Manufacturer
Raritan
Remote Management
HTTP, HTTPS, SNMP 2, SNMP 3, SSH, Telnet
Remote Management Interface
Ethernet 10/100, RS-232
Input Connectors
1
Interface Provided
1 x LAN - RJ-45, 1 x monitoring - RJ-12, 1 x monitoring - RJ-45, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB - 4 pin USB Type B, 2 x USB - 4 pin USB Type A
Emergency Power Off
Active power meter, Cascadable, Current meter, Energy meter, LED display, Overload protection, Power factor meter, Raritan SecureLock Ready, Real power meter, Splash-proof plug, Voltage monitoring
Frequency
50/60 hertz
Input Connector Type
Power NEMA L21-30
Input Voltage Range
AC 190 - 208 V
Input Wiring
3-phase WYE (star)
Max Input Current
24 ampere
Output Connector Quantity
24
Output Connector Type
Power IEC 60320 C13
Power Capacity
8600 volt ampere per kilogram
Power Output Connectors Details
24 x power IEC 60320 C13 - 208 V 12 A
Provided Voltage
AC 208 volt
Required Voltage
AC 208 volt
Form Factor (Power Device)
Rack-mountable
Max Operating Temperature
140 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
5 - 85%
Protection Type
Circuit breaker
Packaged Quantity
1
Product Type
Power distribution unit
Rack Mounting Kit
Included
Subcategory
Power distribution devices
Cables
Power cable - integrated - 10 ft
Height
3.5 inch
Height (Rack Units)
2
Width
17.3 inch
Depth
11.5 inch
Color
Black powder coat
Color Category
Black
Compliant Standards
cULus, FCC Part 15 A, ICES-003 Class A, RoHS, UL
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
