Tech specs
Brand
Ruckus
Product Line
Ruckus
Model
R770
Manufacturer
Ruckus Wireless
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.11w, IEEE 802.1Q, Wi-Fi CERTIFIED 7
Connectivity Technology
Wireless
Data Link Protocols
Bluetooth, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n, ZigBee
Data Transfer Rate
12.22 GBps
Features
2x2:2 streams, 4x4:4 streams, 802.1x authentication, Access Control List (ACL) support, Adaptive band balancing, Airtime Fairness, Airtime-based WLAN Prioritization, Backhaul Technology, BeamFlex+ Smart Antenna Technology, Beamforming technology, Bluetooth Low Energy (BLE), Captive Portal, ChannelFly, Client load balancing, Device fingerprinting, Guest access, HotSpot 2.0, IPv4 and IPv6 dual stack, LLDP support, Low Density Parity Check (LDPC), Multi-Link Operation (MLO), MU-MIMO technology, Port-based VLAN, PowerSave, Preamble puncturing, Quality of Service (QoS), Rate limit, Secure Boot, SmartMesh, SmartRoam, SmartZone, Space Time Blocking Code (STBC), Spectrum Analysis, SpeedFlex, SU-MIMO technology, Trusted Platform Module 2.0 (TPM 2.0), URL filtering, VLAN pooling, Web authentication, Wi-Fi Multimedia (WMM) support, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), WISPr authentication
Form Factor
Desktop / wall / ceiling mountable
Network Band
2.4 GHz, 5 GHz, 6 GHz
Network Standard
IPv4, IPv6
Product Type
Wireless access point
Routing Protocol
GRE
Wireless LAN
802.11a/b/g/n/ac/ax/be, Bluetooth, ZigBee
Interface Provided
1 x 1000Base-T - RJ-45, 1 x 10Gb Ethernet - RJ-45, 1 x USB 2.0 - Type A
Antenna Form Factor
Internal
Antenna Gain Level
4 DBi
Encryption
Dynamic PSK, Opportunistic Wireless Encryption (OWE), PMF, WEP, WPA, WPA2, WPA2-PSK, WPA3, WPA3-SAE, WPA-PSK
Internet of Things (IoT) Compatible
Yes
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
14 degree Fahrenheit
Operating Humidity
0 - 95% (non-condensing)
Authentication Method
RADIUS
Capacity
Concurrent users: 1024, SSIDs total: 36
Country
United States
IoT Communications Technology
Bluetooth Low Energy (LE), Zigbee
Packaged Quantity
1
Ruggedized Design
Indoor
Service Activation
No
Network Device
Channel width: 20 / 40 / 80 / 160 / 320 MHz, Maximum data rate (2.4 GHz): 689 Mbps, Maximum data rate (5 GHz): 5765 Mbps, Maximum data rate (6 GHz): 5765 Mbps
Included Accessories
Adjustable acoustic drop ceiling bracket
Height
2.3 inch
Weight
3 lbs
Width
9.2 inch
Depth
9.2 inch
Color Category
White
Compliant Standards
EN 50121-1, EN 50121-4, EN 60601-1-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, EN 62311, IEC 61373, IEC/EN/UL 60950-1, IEC/EN/UL 62368-1, IEEE 802.15, ISTA 2A, RoHS, UL 2043, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
