Tech specs
Brand
SIIG
Product Line
SIIG
Model
2x1 DisplayPort 4K KVM USB 3.0 Switch
Manufacturer
Siig
Compliant Standards
HDCP 2.2
Features
3D support, 4K resolution support, 7.1 channel audio support, Dolby TrueHD support, DTS-HD support, HDR support, Metal housing, Switch buttons
Form Factor (Hubs & Switches)
Desktop
Ports
2
Product Type
KVM / audio / USB switch
Status Indicators
Online, Select
Subcategory
KVM
Switching Type
DisplayPort / USB
Interface Provided
1 x HDMI output Type A console, 1 x keyboard (USB) Type A console, 1 x mouse (USB) Type A console, 1 x remote selector switches mini-jack, 2 x audio input mini-jack, 2 x audio output mini-jack console, 2 x DisplayPort input, 2 x microphone mini-jack, 2 x microphone mini-jack console, 2 x USB 3.2 Gen 1 Type A, 2 x USB 3.2 Gen 1 Type B
Port Quantity
2
Port Type
KVM / audio / USB
KVP Max Resolution
7680 x 4320
Frequency
50 - 60 hertz
Required Voltage
AC 100 - 240 volt
KVM V-Sync Rate At Max Resolution
60 Hz
Local Users Supported
1 local user
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
140 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Operating Humidity
5 - 90% (non-condensing)
Operating System Required
Apple macOS 10.13 or later, Microsoft Windows 7 / 8 / 10 / 11
Device Type
External power adapter
Keyboard
USB
Packaged Quantity
1
Performance
Video bandwidth (DisplayPort 1.2): 21.6 Gbps, Video bandwidth (DisplayPort 1.4): 32.4 Gbps, Video bandwidth (HDMI): 18 Gbps
Cables
2 x USB 3.2 Gen 1 Type A to Type B cable, IR extender cable
Included Accessories
IR remote
Height
1 inch
Weight
13.26 ounce
Width
7 inch
Depth
3 inch
Color
Black
Color Category
Black
Compliant Standards
FCC, HDCP 2.2, RoHS
Service & Support Details
Limited warranty - 2 years
Limited Warranty
2 Year
