Tech specs
Brand
Sony
Product Line
Sony XDCAM
Model
PXW-Z200
Manufacturer
Sony
Connector Type
2 x audio input (3 pin XLR), Audio input (mini-phone stereo 3.5 mm), Gigabit LAN (RJ-45), HDMI output (19 pin HDMI Type A), Headphones (mini-phone stereo 3.5 mm), Remote control (sub-mini phone stereo 2.5 mm), SDI output (BNC), Timecode in/out (BNC), USB 3.2 (24 pin USB-C)
Display Format
2,764,800 pixels
Image Sensor Size
1.0"
Image Sensor Type
Exmor RS CMOS
Image Sensors
1 CMOS
Touchscreen
No
White Balance
Automatic, Custom, Presets
White Balance Presets
2000K - 15000K
Audio Signal Format
AAC LC, Linear PCM
Microphone Operation Mode
Stereo
Built-in Optical Image Stabilizer
Yes
Camcorder Media Type
Flash card
Camcorder Type
Professional
Composite Video Out
3G HD-SDI, HDMI
Face Detection
Yes
High-Definition Video Support
4K
Image Processor
BIONZ XR
ISO (Max)
16000
Max Frame Rate
120 fps
Max Video Resolution
3840 x 2160
Native ISO
250-16000
Video Capture
XAVC HS - 3840 x 2160 p - 100 fps, XAVC HS - 3840 x 2160 p - 119.88 fps, XAVC HS - 3840 x 2160 p - 23.98 fps, XAVC HS - 3840 x 2160 p - 50 fps, XAVC HS - 3840 x 2160 p - 59.94 fps, XAVC S - 1920 x 1080 p - 23.98 fps, XAVC S - 1920 x 1080 p - 25 fps, XAVC S - 1920 x 1080 p - 29.97 fps, XAVC S - 1920 x 1080 p - 50 fps, XAVC S - 1920 x 1080 p - 59.94 fps, XAVC S - 3840 x 2160 p - 100 fps, XAVC S - 3840 x 2160 p - 119.88 fps, XAVC S - 3840 x 2160 p - 23.98 fps, XAVC S - 3840 x 2160 p - 50 fps, XAVC S - 3840 x 2160 p - 59.94 fps
Connectivity Features
Remote control via LAN
Display Form Factor
Rotating
Features
Proxy recording, Selectable frame rates
Gain Selection
-3 to +36 dB in 1 dB
Max Shutter Speed
1/8000 second (time unit)
Memory Card Slot
Dual SD card
Memory Cards Supported
Memory Stick, SD Memory Card, SD UHS-I Memory Card, SD UHS-II Memory Card, SDHC UHS-I Memory Card, SDHC UHS-II Memory Card, SDXC UHS-I Memory Card, SDXC UHS-II Memory Card
Screen Size
3.5 inch
Screen Size (metric)
8.8 centimetre
Shortest Shutter Speed
12 lux
Type
LCD display
Wireless Interface
IEEE 802.11a/b/g/n/ac, NFC (Near Field Communication)
Battery Chemistry
Lithium ion
Battery Form Factor
Manufacturer-specific
Battery Model Supported
Sony BP-U100, Sony BP-U35, Sony BP-U70
Details
Sony BP-U100 Li-ion rechargeable battery - 6400 mAh, Sony BP-U30 Li-ion rechargeable battery - 2420 mAh (included), Sony BP-U70 Li-ion rechargeable battery - 4800 mAh
AE/AF Control
AF Assist, AF Subject Shift Sensivity, AF Transition Speed, Human detection AF
Autofocus
Automatic, Manual
Autofocus Points
475
Autofocus Type
TTL contrast and phase detection
Effective Sensor Resolution
14,000,000 pixels
Focal Length (35mm)
24 - 480mm
Image Stabilization
Optical
Lens Aperture
F/2.8-4.5
Lens Features
Chromatic Aberration Reduction, Distortion reduce, Fast Hybrid AF
Lens Type
Zoom lens
Max Focal Length
154.21 millimetre
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
140 degree Fahrenheit
Min Focal Length
7.71 millimetre
Min Focus Distance
0.4 inch
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Optical Sensor Size (metric)
8.8 x 13.2 mm
Optical Zoom
20
Total Pixels
20,900,000 pixels
Video Formats
AVC, H.264, H.265, MXF, XAVC HS, XAVC S
Viewfinder Type
OLED
Zoom Adjustment
Manual (by ring), Motorized drive
Features
AI-powered, Auto framing, Auto Tracing White Balance, Automatic Gain Control (AGC), Built-in cooling fan, Built-in Electronic Variable ND Filter, Dual image stabilization, Hybrid Log-Gamma (HLG) recording, ITU709 compatibility, Live RTMP streaming, Optical Low Pass Filter (OLFP), Peripheral shading correction, S-Cinetone, Secure Reliable Transport (SRT) ready, S-Log3 gamma setting, Slow motion recording
Night Mode
1/4 to 1/128
Optical Viewfinder Dioptric Correction Range
-4 to +3
Packaged Quantity
1
Product Type
Camcorder
Shutter Type
Electronic
Viewfinder Color Support
Color
Viewfinder Diagonal Size
0.39 inch
Viewfinder Diagonal Size (metric)
1 centimetre
Viewfinder Resolution
2,359,296 pixels
Accessories Included
AC power adapter, Battery Charger, cold shoe mount, cold shoe mount adapter, Eyecup, LCD screen hood, Lens Cap, Lens Hood, microphone holder
Memory Card Included
No
Height
7.9 inch
Weight
4.32 lbs
Weight Details
Camera only: 4.3 lbs, Camera with battery, lens hood, eyecup and memory card: 5.3 lbs
Width
6.9 inch
Depth
14.6 inch
Filter Size
72 millimetre
Color Category
Black
