Tech specs
Brand
D-Link
Product Line
D-Link SmartPro
Model
DGS-1510-20
Manufacturer
D-Link
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Features
Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Bandwidth control, Cable Diagnostics Function, D-Link Green Technology, DoS attack prevention, Energy Efficient Ethernet, Flow control, Full duplex mode, Half duplex mode, IGMP snooping, IPv6 support, Link Aggregation Control Protocol (LACP), LLDP support, Loopback, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Quality of Service (QoS), RADIUS support, Rapid Spanning Tree Protocol (RSTP) support, Safeguard Engine, Spanning Tree Protocol (STP) support, Store and forward, VLAN support
Form Factor (Hubs & Switches)
Desktop, Rack-mountable
Jumbo Frame Support
9000 bytes
MAC Address Table Size
16000 entries
Manageable
Yes
Max Units In A Stack
6
Ports
20
Product Type
Switch
Remote Management
CLI, HTTP, RMON 1, SNMP 1, SNMP 2c, SNMP 3, Telnet
Routing Protocol
Static IP routing
Stackable
Stackable
Status Indicators
Fan, Link/activity, Port transmission speed, Power
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
QSFP Slots
10 Gigabit SFP+
Interface Provided
16 x 1000Base-T RJ-45, 2 x 1000Base-X SFP, 2 x 10GBase-X SFP+
Port Quantity
16
Port Type
10/100/1000
Ports Type (2nd)
Gigabit SFP
Frequency
50/60 hertz
Power Consumption Operational
20.3 watt
Encryption
PEAP, SSL, TLS, TTLS
Humidity Range Storage
0 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Operating Humidity
0 - 95% (non-condensing)
Authentication Method
RADIUS
Capacity
ARP entries: 256, IPv4 routes: 64, IPv6 routes: 32
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 56.54 Mpps, Stacking bandwidth: 20 Gbps, Switching capacity: 76 Gbps
Ports (2nd) Quantity
2
Ports (3rd) Quantity
2
Height
1.7 inch
Height (Rack Units)
1
Weight
2.73 lbs
Width
11 inch
Depth
7.1 inch
Compliant Standards
BSMI, CB, CCC, C-Tick, cUL, FCC, VCCI
ENERGY STAR Certified
No
